Chapter 3
Assembling and Mounting a Cisco TelePresence System 1100
Step 7
Continue to the
installation.
Attaching the Light Reflector, Display, and Cabinet
To attach the light reflector and display to the mounting bracket, and to attach the cabinet to the wall,
complete the following steps:
Remove the light reflector from its packaging.
Step 1
OL-19695-01
"Attaching the Light Reflector, Display, and Cabinet" section on page 3-27
Cisco TelePresence System 1100 Assembly, First-Time Setup, and Field Replaceable Unit Guide
Attaching the Light Reflector, Display, and Cabinet
to complete
3-27
