Cisco TelePresence System 1100 Assembly Manual page 103

Chapter 4 First-Time Setup
Adjust the camera zoom by completing the following steps:
Step 10
a.
Note
b.
c.
Figure 4-16 Adjusting the Camera Zoom
Note curved
lines touching
screen border
Tighten the thumbscrews for the zoom and focus rings.
Step 11
Click Hide Camera Targets.
Step 12
Perform final zoom adjustments to ensure that the camera projects a life-size image by completing the
Step 13
following steps:
a.
b.
c.
Click Done to finish the camera zoom procedure.
Step 14
OL-19695-01
Loosen the thumbscrew for the zoom ring on the camera lens.
The zoom ring is labeled "W-T".
Adjust the camera zoom so that the black curved lines on each side of the target touch the edge of
the display screen.
After you adjust the zoom, make any required adjustments to the focus with the focus ring.
Using the paper ruler or tape measure, measure 12 inches or 250 cm from the rear edge of the table.
Using another tape measure, measure 12 inches or 250 cm from where the table edge is projected
on the display.
If the measurements do not match, perform additional adjustments to the zoom until the
measurements are the same.
Cisco TelePresence System 1100 Assembly, First-Time Setup, and Field Replaceable Unit Guide
Setting Up the Camera
Red plus
sign within
black cross
4-23
