Interpreting Leds - Oracle SPARC T7-1 Service Manual

Component
SPM
Related Information
"Log In to Oracle ILOM (Service)" on page 24
■
"Identify Faulted Components" on page 24
■
"Identify Disabled Components" on page 26
■

Interpreting LEDs

Use these steps to determine if an LED indicates that a component has failed.
Step
1.
2.
Related Information
"Checking for Faults" on page 23
■
"Performing Advanced Troubleshooting" on page 34
■
"Clear a Fault Manually" on page 39
■
Oracle ILOM Target
/SYS/MB/SPM
Description
Check the LEDs on the front and rear of the server.
Check the LEDs on the individual components.
Component LEDs might not be lit even though the
component is faulty. Rely on software to determine
if a component is faulty, see "Identify Faulted
Components" on page 24.
Links
"Servicing the SPM" on page 131
Links
■ "Front Panel Controls and
LEDs" on page 30
■ "Rear Panel Controls and
LEDs" on page 32
■ "Servicing Drives" on page 61
■ "Servicing Fan Modules" on page 73
■ "Servicing Power Supplies" on page 83
■ "Servicing Memory Risers and
DIMMs" on page 89
■ "Servicing PCIe Cards" on page 113
■ "Servicing the Motherboard" on page 147
Detecting and Managing Faults
Interpreting LEDs
29
