Oracle SPARC T7-1 Service Manual page 21

Device
PCIe 1
PCIe 2
PCIe 3
PCIe 4
PCIe 5
PCIe 6
NET 0
NET 1
NET 2
NET 3
HDD 0
HDD 1
HDD 2
NVMe 0
HDD 3
NVMe 1
HDD 4
NVMe 2
HDD 5
NVMe 3
HDD 6
HDD 7
DVD
Related Information
"Component Names Displayed by Diagnostic Software " on page 27
■
"Front Panel Components (Service)" on page 13
■
"Rear Panel Components (Service)" on page 15
■
"Internal Component Locations" on page 16
■
"Server Block Diagram" on page 19
■
Path
/pci@304/pci@1
/pci@303/pci@2
/pci@303/pci@1
/pci@302/pci@1
/pci@302/pci@2
/pci@301/pci@1
/pci@300/pci@1/network@0
/pci@300/pci@1/network@0,1
/pci@300/pci@3/network@0
/pci@300/pci@3/network@0,1
/pci@301/pci@2/scsi@0/disk@p0
/pci@301/pci@2/scsi@0/disk@p1
/pci@301/pci@2/scsi@0/disk@p2
/pci@303/pci@1/pci@0/pci@6/nvme@0/disk@1
/pci@301/pci@2/scsi@0/disk@p3
/pci@303/pci@1/pci@0/pci@7/nvme@0/disk@1
/pci@301/pci@2/scsi@0/disk@p4
/pci@303/pci@1/pci@0/pci@4/nvme@0/disk@1
/pci@301/pci@2/scsi@0/disk@p4
/pci@303/pci@1/pci@0/pci@5/nvme@0/disk@1
/pci@301/pci@2/scsi@0/disk@p6
/pci@301/pci@2/scsi@0/disk@p7
/pci@300/pci@2/usb@0/hub@8/device@1/storage@0/disk@0
Server Block Diagram
Identifying Components 21
