Servicing the eUSB Drive

The eUSB drive is mounted on the motherboard towards the front on the power supply side.
These topics describe how to service the eUSB drive.
"Install the eUSB Drive" on page 123
■
"Remove the eUSB Drive" on page 121
■
Related Information
"Detecting and Managing Faults" on page 23
■

Remove the eUSB Drive

You can perform this cold-service procedure. Power down the server completely before
performing this procedure.
This procedure requires that you handle components that are sensitive to ESD. This
Caution -
sensitivity can cause the components to fail. To avoid damage, ensure that you follow antistatic
practices as described in
1. Prepare the system for service.
See "Preparing for Service" on page
2. Remove the screw that attaches the eUSB drive to the motherboard.
"Prevent ESD Damage" on page
41.
50.
Servicing the eUSB Drive 121
