Printhead Skew + Paper Feed Skew
Duplex Skew Specification
Side
Print Sequence Thru Printer
16 lb. to 24 lb.
All Other Papers
Card Stock
Labels
•
Paper, Dual-Web Paper
•
Vinyl, Polyester (less than or equal 92# liner)
Print Registration
Initial adjustment (adjustable in increments of T=0.3mm, B=0.5mm, R and L=0.2mm)
•
Left print position accuracy (scanning direction): +/-0.5mm - start on scan
•
Top print position accuracy (feeding direction): +/-0.5 mm - start on scan
•
Horizontal page width accuracy: +/-0.5mm - mirror motor
•
Vertical page length accuracy: +/-0.5mm - drive motor
Print Position Error
Measured at any point in the printable area using core media papers.
•
Vertical (process): +/-0.7mm
•
Horizontal (magnification): +/-0.7mm
1
2nd
+/-0.007 mm/mm
+/-0.010 mm/mm
+/-0.007 mm/mm
+/-0.010 mm/mm
+/-0.010 mm/mm
Repair information
265
4062
2
1st
+/-0.005 mm/mm
+/-0.005 mm/mm
+/-0.007 mm/mm
+/-0.010 mm/mm
+/-0.010 mm/mm
