Generator Removal and Installation

Removal
1) Disconnect the (–) battery lead wire. Refer to
"Battery Removal and Installation (Page 1J-13)".
2) Drain engine oil. Refer to "Engine Oil and Filter
Replacement in Section 0B (Page 0B-7)".
3) Remove the left side cover and left footrest
mudguard. Refer to "Exterior Parts Removal and
Installation in Section 9D (Page 9D-3)".
4) Remove the recoil starter assembly (1).
5) Remove the starter cup nut with a suitable bar.
6) Remove the starter cup (2).
7) Disconnect the oil hose (3).
3
B827H11A06004
1
I827H11A0006-01
10) Remove the bolt, spring and transfer gearshift cam
2
I827H11A0007-01
11) Disconnect the CKP sensor lead wire coupler (8)
I827H11A0008-01
8) Disengage the gearshift link arm (4) (LT-F400/F) and
transfer gearshift arm (5).
4
9) Remove the speedometer gearbox (6).
stopper (7) (LT-F400/F).
7
and generator lead wire coupler (9).
Charging System: 1J-5
5
I827H11A0009-01
6
I827H11A0010-01
I827H11A0011-01
9
8
I827H11A0012-01
