Front Brake Pad Inspection

Refer to "Front Brake System Inspection in Section 0B
(Page 0B-15)".

Front Brake Pad Replacement

1) Remove the front wheel assembly. Refer to "Front /
Rear Wheel Removal and Installation in Section 2D
(Page 2D-3)".
2) Loosen the pad mounting pins (1).
3) Remove the brake caliper mounting bolts (2).
CAUTION
!
Do not operate the brake lever while
removing the brake caliper.
4) Remove the brake pads by removing the pad
mounting pin.
NOTE
When removing the pads, push the piston all
the way into the brake caliper.
5) Clean up the caliper especially around the caliper
piston.
B827H14206002
B827H14206003
1
I827H1420001-01
2
I827H1420002-01
6) Install the new brake pads.
CAUTION
!
Replace the brake pads as a set, otherwise
braking performance will be adversely
affected.
7) Apply a small quantity of thread lock to the brake pad
mounting pins (1).
: Thread lock cement 99000–32050
(THREAD LOCK CEMENT 1342 or equivalent)
8) Temporarily tighten the front brake pad mounting
pins (1).
Front Brakes: 4B-2
I827H1420003-01
1
I827H1420004-02
