Front / Rear Wheel Removal and Installation

NOTE
Make sure that the vehicle is supported
securely.
Removal
1) Place the vehicle on level ground.
2) Support the vehicle with a jack or wooden block.
CAUTION
!
Make sure that the vehicle is supported
securely.
3) Remove the wheel.
Installation
Install the wheel in the reverse order of removal. Pay
attention to the following points:
• Install the wheel and tighten the wheel set nuts
temporarily.
WARNING
!
The directional arrow on the tire should point
to the wheel rotation, when remounting the
wheel.
• Tighten the wheel set nuts to the specified torque.
B827H12406002
NOTE
Tighten the wheel set nuts diagonally.
Tightening torque
Wheel set nut (Front and rear) (a): 60 N·m (6.0
kgf-m, 43.5 lb-ft)

Tire Removal and Installation

1) Remove the wheel from vehicle. Refer to "Front /
Rear Wheel Removal and Installation (Page 2D-3)".
2) After removing the air valve caps, release the tire
pressure by depressing the valves.
I827H1240001-01
NOTE
To properly remove the tire, if a pneumatic
tire changer is not available, remove the tire
as shown in the following procedures.
3) Dismount the bead from the rim completely as
shown in the figure.
I827H1240002-01
Wheels and Tires: 2D-3
