Brake Shoe
Inspect the brake shoes for wear or damage. If they are
worn or damaged, replace the shoes with new ones.
CAUTION
!
Replace the brake shoes as a set, otherwise
braking performance will be adversely
affected.
Service Data (LT-A400/F, LT-F400/F)
Brake
Unit: mm (in)
Item
Rear brake lever play
Rear brake pedal free travel
Rear brake drum I.D.

Tightening Torque Specifications

Fastening part
Rear brake cam lever nut
Rear brake anchor panel bolt
Rear hub nut
NOTE
The specified tightening torque is also described in the following.
"Rear Brake Components (Page 4C-2)"
"Rear Brake Construction (Page 4C-3)"
Reference:
For the tightening torque of fastener not specified in this section, refer to "Tightening Torque List (LT-A400/F) in
Section 0C (Page 0C-9)".
Dust Seal
Inspect the dust seal wear or damage. If it is worn or
damaged, replace the dust seal with a new one.
I827H1430037-01

Specifications

Standard
3 – 5 (0.1 – 0.2)
20 – 30 (0.8 – 1.2)
—
Tightening torque
N⋅m kgf-m
11 1.1
32 3.2
121 12.1
Rear Brakes:
I827H1430038-01
B827H14307001
Limit
—
—
160.7 (6.33)
B827H14307002
Note
lb-ft
8.0 (Page 4C-6)
23.0 (Page 4C-6)
87.5 (Page 4C-8)
4C-9
