List of shims (for drive bevel gear)
Part No.
24935-19B00-
025: 0.25 mm
(0.0098 in)
Combined
shim
24935-19B00-
030: 0.30 mm
(0.0118 in)
24935-19B00-
035: 0.35 mm
(0.0138 in)
Part No.
24935-03G50-055
24935-03G50-058
24935-03G50-060
24935-03G50-063
24935-03G50-065
24935-03G50-068
24935-03G50-070
24935-03G50-073
24935-03G50-075
24935-03G50-078
24935-03G50-080
24935-03G50-083
24935-03G50-085
24935-03G50-088
24935-03G50-090
24935-03G50-093
24935-03G50-095
24935-03G50-098
24935-03G50-100
24935-03G50-103
24935-03G50-105
24935-03G50-108
24935-03G50-110
24935-03G50-113
24935-03G50-115
24935-03G50-118
24935-03G50-120
24935-03G50-123
24935-03G50-125
24935-03G50-128
24935-03G50-130
Shim thickness
0.25+0.25=0.50 mm
(0.0197 in)
0.25+0.30=0.55 mm
(0.0217 in)
0.30+0.30=0.60 mm
(0.0236 in)
0.30+0.35=0.65 mm
(0.0256 in)
0.35+0.35=0.70 mm
(0.0276)
0.25+0.25+ 0.25=0.75 mm
(0.0295 in)
0.25+0.25+0.30=0.80 mm
(0.0315 in)
0.25+0.25+0.35=0.85 mm
(0.0335 in)
Shim thickness
0.550 mm (0.0217 in)
0.575 mm (0.0226 in)
0.600 mm (0.0236 in)
0.625 mm (0.0246 in)
0.650 mm (0.0256 in)
0.675 mm (0.0266 in)
0.700 mm (0.0276 in)
0.725 mm (0.0285 in)
0.750 mm (0.0295 in)
0.775 mm (0.0305 in)
0.800 mm (0.0315 in)
0.825 mm (0.0325 in)
0.850 mm (0.0335 in)
0.875 mm (0.0344 in)
0.900 mm (0.0354 in)
0.925 mm (0.0364 in)
0.950 mm (0.0374 in)
0.975 mm (0.0384 in)
1.000 mm (0.0394 in)
1.025 mm (0.0404 in)
1.050 mm (0.0413 in)
1.075 mm (0.0423 in)
1.100 mm (0.0433 in)
1.125 mm (0.0443 in)
1.150 mm (0.0453 in)
1.175 mm (0.0463 in)
1.200 mm (0.0472 in)
1.225 mm (0.0482 in)
1.250 mm (0.0492 in)
1.275 mm (0.0502 in)
1.300 mm (0.0512 in)
Final Assembly
1) After adjusting the gear backlash and tooth contact
correctly, remove the rear output shaft and drive
bevel gear.
2) Clean off any machinist's dye or paste from the gear
teeth, and lubricate the teeth with engine oil.
3) Install the drive bevel gear. Refer to "Drive Bevel
Gear Removal and Installation (LT-A400/F)
(Page 3D-13)".
4) Install the rear output shaft. Refer to "Rear Output
Shaft Disassembly and Assembly (LT-F400/F)
(Page 3D-7)" and "Output Shaft Removal and
Installation (Page 3D-3)".
Propeller Shafts: 3D-19
