Reel
Inspect the reel for wear or damage. If any defects are
found, replace the reel with a new one.
Service Data (LT-A400/F, LT-F400/F)
Unit: mm (in)
Item
Starter motor brush length
Starter relay resistance

Tightening Torque Specifications

Fastening part
Starter motor mounting bolt
Starter motor lead wire mounting nut
Starter motor housing bolt
Starter clutch bolt
Recoil starter mounting bolt
Recoil starter center nut
NOTE
The specified tightening torque is also described in the following.
"Starter Motor Components (Page 1I-3)"
Reference:
For the tightening torque of fastener not specified in this section, refer to "Tightening Torque List (LT-A400/F) in
Section 0C (Page 0C-9)".

Recommended Service Material

Material
Grease
Moly paste
Thread lock cement
I831G1190062-02

Specifications

Standard
Limit

Special Tools and Equipment

SUZUKI recommended product or Specification
SUZUKI SUPER GREASE A or
equivalent
SUZUKI Moly paste or equivalent
THREAD LOCK CEMENT SUPER
1322 or equivalent
Rope
Inspect the rope for damage. If any defects are found,
replace the rope with a new one.
Specification
10 (0.39)
6.5 (0.26)
3 – 5 Ω
Tightening torque
N⋅m kgf-m
10 1.0
7 0.7
3.5 0.35
26 2.6
10 1.0
12 1.2
P/No.: 99000–25010
P/No.: 99000–25140
P/No.: 99000–32110
Starting System:
I831G1190063-01
B827H11907001
Note
B827H11907002
Note
lb-ft
7.0 (Page 1I-4)
5.0 (Page 1I-4)
2.5 (Page 1I-4)
19.0 (Page 1I-10)
7.0 (Page 1I-13)
8.5 (Page 1I-15)
B827H11908001
Note
(Page 1I-3) / (Page 1I-4)
/ (Page 1I-14) /
(Page 1I-15)
(Page 1I-4)
(Page 1I-13)
1I-16
