Fuel System Description

The fuel system consists of a fuel tank, fuel filter, fuel valve, vacuum hose, fuel hose and carburetor assembly. When

there is negative pressure (vacuum) in the combustion chamber, the fuel is able to flow from the fuel tank, through the

fuel valve and then to the carburetor assembly.

Fuel System:

B827H11701001

I827H1170033-01
