Upload User's Signal Standard Table – Control Byte #92 (5Ch)
Description: Upload user's signal standard table to Cell Master.
Bytes to Follow: Variable (64 bytes * n ) where n is the total record of the signal standards.
Each record has the following data field.
1– 2):
3- 42):
43-46):
47-50):
51-52):
53-54):
55-58):
59-62):
63-64):
65-128):
129-192):
Etc.
Cell Master Returns: 1 byte
255 (FFh) Operation Complete Byte
224 (E0h) Parameter Error: Invalid signal standard
238 (EEh) Time Out Error
Measure OCC BW % of Power – Control Byte #96 (60h)
Description: Measure OCC BW with % of Power method.
If option 6 is installed and the frequency extension module is attached, the OBW frequencies will be scaled by the
scale factor of the module. If the module is not attached, the OBW frequencies are sent in Hz. Use Control Word
A203 to determine whether a module is attached and the appropriate scale factor.
Bytes to Follow: 4 bytes
1) % of Power (Highest byte)
2) % of Power
3) % of Power
4) % of Power (Lowest byte)
Spectrum Master Returns: 16 bytes
1-4) Occupied Bandwidth (in Hz)
5-8) Measure dB down (dB * 100,000)
9-12) Low Frequency OCC BW
13-16) High Frequency OCC BW
97
Record type ( Record type = 0xffff means last record )
Signal Standard Name (maximum 40 bytes)
Center Frequency of first channel of uplink(in Hz)
Center Frequency of first channel of downlink (in Hz)
Start Channel Number
Stop Channel Number
Channel Band width (in Hz)
Channel Spacing (in Hz)
Channel Step.
nd
2 record.
rd
3 record.
th
(in 100 of %, 9123 = 91.23% )
