98) Start Channel
99) Start Channel
100) Start Channel (Lowest Byte)
101 – 124) Signal Standard Name, 24 bytes in ASCII
125 – 152) Reserved
153 – 272) Channel Scanner Data
For Interference Analyzer RSSI Mode
57) Center Frequency (Highest Byte)
58) Center Frequency
59) Center Frequency
60) Center Frequency (Lowest Byte)
61) Reference Level (Highest Byte)
62) Reference Level
63) Reference Level
64) Reference Level (Lowest Byte)
65) Scale (Highest Byte)
66) Scale
67) Scale
68) Scale (Lowest Byte)
69) RBW (Highest Byte)
70) RBW
71) RBW
72) RBW (Lowest Byte)
73) VBW (Highest Byte)
74) VBW
75) VBW
76) VBW (Lowest Byte)
77) Status Byte 1
78) Reference Level Offset (Highest Byte)
79) Reference Level Offset
80) Reference Level Offset
81) Reference Level Offset (Lowest Byte)
82) External Reference Frequency
83) Signal Standard (Highest Byte)
84) Signal Standard (Lowest Byte)
85) Channel (Highest Byte)
86) Channel (Lowest Byte)
87) Min RSSI Measured (Highest Byte)
88) Min RSSI Measured
89) Min RSSI Measured
90) Min RSSI Measured (Lowest Byte)
91) Max RSSI Measured (Highest Byte)
152
20 points, 6 bytes per point. First 2 bytes are channel numbers(Invalid channels sent as 0xFFFF) and 4 bytes are
values. Value sent as (value in dBm) * 1000 + 270,000
153
000 - Positive Peak, 010 – RMS Averaging, 100 – Negative Peak, 110 – Sampling Mode
154
Frequency in MHz, OFF if 0
155
Invalid channels are sent as 0xFFFF
43
152
Bit 0 - Detection Algorithm (Lowest Bit)
Bit 1 - Detection Algorithm
Bit 2 - Detection Algorithm (Highest Bit)
Bit 3 - Not Used
Bit 4 - Not Used
Bit 5 - Not Used
Bit 6 - Not Used
155
153
154
