Anritsu Spectrum Master MS2711D Programming Manual page 21

272) Printer Type (see control byte #30)
273) Trace A/B Status
(LSB)
274) Trace B Trace ID (0 = previous A data, 1-200 = saved trace id, 255 = none)
275) Status Byte 8:
(LSB)
276) Status Byte 9: (0b = Off , 1b = On)
(LSB)
277) N/A
278) N/A
279) N/A
280) N/A
281) N/A
282) N/A
283) N/A
284) N/A
285) SSB/CW BFO Adjustment Value (0-255)
286) N/A
287) N/A
288) N/A
289) N/A
290) RTC Battery Voltage
291) RTC Battery Voltage (Lower byte)
292) Motherboard PCB ID
293) Motherboard PCB ID (Lower byte)
294) N/A
295) N/A
296-310) Not Used
24
"value" sent as (value in Volts * 10)
25
"value" sent as (value in Volts * 1000)
20
bit 5 : Channel Power On/Off
bit 6 : Adjacent Channel Power On/Off
bit 7 : Occupied Bandwidth On/Off
bit 0-1 : Trace A (00b = A only 01b = A – B 10b = A + B)
bit 2 : Trace B On/Off (0b = Off, 1b = On)
bits 3-7 : Not Used
bits 0-6 : Number of Sweeps to Average (1-25, 1 implies averaging Off)
bit 7 : Reserved
bit 0 : Preamp Hardware Installed (1b = Yes, 0b = No)
bit 1 : Preamp On/Off
bit 2 : N/A
bit 3 : Dynamic Attenuation On/Off
bit 4 : Normalization On/Off
bit 5 : Bias Tee On/Off
bit 6 : Scale Type (0b = Log, 1b = Linear)
bit 7 : Linear Units (0b = Watts, 1b = Volts)
24
(Higher byte)
25
(Higher byte)
12
