Write Antenna – Control Byte #82 (52h)
Description: Receives an antenna to the Spectrum Master via the serial port.
An antenna is described with an index into the list (1-10) and an ASCII name that appears in the list on the Spectrum
Master. Each antenna can have up to 60 antenna factors. Each antenna factor has an associated frequency and
value. These are specified one at a time.
Frequencies are sent in Hz scaled by the Scale Factor.
The value of the antenna factor should be sent as (value * 100).
Bytes to Follow: 26 – 380, depending on the number of antenna factors
1) Antenna List Index (1-10)
2-17) Antenna Name (in ASCII)
18) Number of Antenna Factors (max = 60)
19-20) Frequency Scale Factor (in Hz)
For each antenna factor:
1) Frequency (scaled by Scale Factor) (Highest byte)
2) Frequency (scaled by Scale Factor)
3) Frequency (scaled by Scale Factor)
4) Frequency (scaled by Scale Factor) (Lowest byte)
5) Antenna Factor (Higher byte)
6) Antenna Factor (Lower byte)
Spectrum Master Returns: 1 byte
1) 255 (FFh) Operation Complete Byte
224 (E0h) Parameter Error
238 (EEh) Time Out Error
