Get Signal Standard Name – Control Word (A501h)
Description: Get the ASCII signal standard corresponding to a specified Index. This command can be used in any
measurement mode.
Bytes to follow: 2
1) Index (Highest Byte)
2) Index (Lowest Byte)
Cell Master Returns: 20 bytes
1 – 20) Standard Name in ASCII
Perform Noise Diode Cal – Control Word (A505h)
Description: Performs noise diode calibration on SPA board
Bytes to follow: 0
Cell Master Returns: 1 byte
255 (FFh) Operation Complete Byte
224 (E0h) Parameter Error: Invalid channel
238 (EEh) Time Out Error
Set Bias T Voltage – Control Word (A506h)
Description: Motherboards beginning with 64968 have a programmable Bias T. This command sets the Bias T
voltage between 12 and 24 volts.
Bytes to follow: 1
1) Bias T Voltage
Cell Master Returns: 1 byte
255 (FFh) Operation Complete Byte
224 (E0h) Parameter Error: Invalid channel
238 (EEh) Time Out Error
Select Function in IA Measurement Mode – Control Word (A700h)
This command is available only with option 25.
Description: Selects measurement function in Interference Analysis mode.
Bytes to Follow: 1 bytes
1) Function ID (0:Spectrum; 1:Spectrogram; 2: Signal strength; 3: RSSI; 4: Signal ID)
Cell Master Returns: 1 byte
255 (FFh) Operation Complete Byte
224 (E0h) Parameter Error: Module not attached
238 (EEh) Time Out Error
