Anritsu Spectrum Master MS2711D Programming Manual page 38

98) Single Limit
99) Single Limit
100) Single Limit (Lowest byte)
101) Multiple Upper Limit 1 Start X
102) Multiple Upper Limit 1 Start X
103) Multiple Upper Limit 1 Start X
104) Multiple Upper Limit 1 Start X (Lowest byte)
105) Multiple Upper Limit 1 Start Y (Power Level
106) Multiple Upper Limit 1 Start Y (Power Level)
107) Multiple Upper Limit 1 Start Y (Power Level)
108) Multiple Upper Limit 1 Start Y (Power Level) (Lowest byte)
109) Multiple Upper Limit 1 End X
110) Multiple Upper Limit 1 End X
111) Multiple Upper Limit 1 End X
112) Multiple Upper Limit 1 End X (Lowest byte)
113) Multiple Upper Limit 1 End Y (Power Level) (Highest byte)
114) Multiple Upper Limit 1 End Y (Power Level)
115) Multiple Upper Limit 1 End Y (Power Level)
116) Multiple Upper Limit 1 End Y (Power Level) (Lowest byte)
117-260) Multiple Upper Limits 2-5, Multiple Lower Limits 1-5 (see bytes 101-116 for format)
261) RBW Setting (Frequency in Hz) (Highest byte)
262) RBW Setting (Frequency in Hz)
263) RBW Setting (Frequency in Hz)
264) RBW Setting (Frequency in Hz) (Lowest byte)
265) VBW Setting (Frequency in Hz) (Highest byte)
266) VBW Setting (Frequency in Hz)
267) VBW Setting (Frequency in Hz)
268) VBW Setting (Frequency in Hz) (Lowest byte)
269) OCC BW Method (0b = % of power, 1b = dB down)
270) OCC BW % Value
271) OCC BW dBc
272) Attenuation
273) Attenuation
274) Attenuation
275) Attenuation (Lowest byte)
276-291)Antenna Name(16 bytes in ASCII)
292) Status Byte 1: ( 0b = Off , 1b = On)
(LSB)
293) Status Byte 2: ( 0b = Off , 1b = On)
(LSB)
103
Scaled by Frequency Scale Factor (bytes 335-336)
104
Value sent as ( value in dBm * 1000 ) + 270,000
105
Scaled by Frequency Scale Factor (bytes 335-336)
106
% value is 0-99
107
dBc value 0 – 120 dBc
108
Value sent as ( value in dB * 1000 )
37
103
105
(Highest byte)
106
107
108
(Highest byte)
bit 0 : Marker 1 On/Off
bit 1 : Marker 2 On/Off
bit 2 : Marker 3 On/Off
bit 3 : Marker 4 On/Off
bit 4 : Marker 5 On/Off
bit 5 : Marker 6 On/Off
bits 6-7: Not Used
bit 0 : Not Used
bit 1 : Marker 2 Delta On/Off
bit 2 : Marker 3 Delta On/Off
bit 3 : Marker 4 Delta On/Off
(Highest byte)
104
) (Highest byte)
