Anritsu Spectrum Master MS2711D Programming Manual page 66

253) Status Byte 4 : ( 0b = Off/Beep if data is BELOW line ,
(LSB)
254) Status Byte 5 : ( 0b = Off/Beep if data is BELOW line ,
(LSB)
255) Status Byte 6: (0b = Off, 1b = On)
(LSB)
256) Status Byte 7: (0b = Off, 1b = On)
(LSB) bit 0: Interference Analysis On/Off
257) Reference Level Offset
258) Reference Level Offset
259) Reference Level Offset
260) Reference Level Offset (Lowest byte)
261) External Reference Frequency
262) Signal Standard
263) Signal Standard (Lower byte)
264) Channel Selection
265) Channel Selection (Lower byte)
266) Trigger Type
267) Interference Analysis Frequency
255
Beep level is always 0b for lower segmented limit line
256
Value sent as (value in dBm * 1000) + 270,000
257
1 byte in MHz (i.e. 20 = 20MHz)
258
Index into Standard List (use control byte #89 to retrieve the ASCII string name). "No Standard" sent as FFFEh
259
"No Channel" is sent as FFFEh
260
Trigger Type – 00h = Single, 01h = Free Run, 02h = Video, 03h = External
261
Scaled by Frequency Scale Factor (bytes 301-302)
65
1b = On/Beep if data is ABOVE line)
bit 0 : SPA Multiple Limit Upper Segment 3 Status On/Off
bit 1 : SPA Multiple Limit Upper Segment 3 Beep Level ABOVE/BELOW
bit 2 : SPA Multiple Limit Upper Segment 4 Status On/Off
bit 3 : SPA Multiple Limit Upper Segment 4 Beep Level ABOVE/BELOW
bit 4 : SPA Multiple Limit Upper Segment 5 Status On/Off
bit 5 : SPA Multiple Limit Upper Segment 5 Beep Level ABOVE/BELOW
bit 6 : SPA Multiple Limit Lower Segment 1 Status On/Off
bit 7 : SPA Multiple Limit Lower Segment 1 Beep Level ABOVE/BELOW
1b = On/Beep if data is ABOVE line)
bit 0 : SPA Multiple Limit Lower Segment 2 Status On/Off
bit 1 : SPA Multiple Limit Lower Segment 2 Beep Level ABOVE/BELOW
bit 2 : SPA Multiple Limit Lower Segment 3 Status On/Off
bit 3 : SPA Multiple Limit Lower Segment 3 Beep Level ABOVE/BELOW
bit 4 : SPA Multiple Limit Lower Segment 4 Status On/Off
bit 5 : SPA Multiple Limit Lower Segment 4 Beep Level ABOVE/BELOW
bit 6 : SPA Multiple Limit Lower Segment 5 Status On/Off
bit 7 : SPA Multiple Limit Lower Segment 5 Beep Level ABOVE/BELOW
bit 0 : Antenna Factors Correction On/Off
bit 1 : Bias Tee On/Off (Option 10)
bit 2 : Amplitude Units (Linear) – 00b = Watts 01b = Volts
bits 3-4 : Amplitude Units (Log) - 00b = dBm 01b = dBV 10b = dBmV 11b = dBuV
bits 5-6 : Detection Alg (00b = pos. peak 01b = RMS Averaging 10b = neg. peak 11b =
Sampling Mode)
bit 7 : Units Type (0b = Log 1b = Linear)
bit 1: C/I Measurement On/Off
bit 2: RBW Coupling (1b = Auto, 0b = Manual)
bit 3: VBW Coupling (1b = Auto, 0b = Manual)
bit 4: Attenuation Coupling (1b = Auto, 0b = Manual)
bit 5: Channel Power On/Off
bit 6: Adjacent Channel Power On/Off
bit 7: Occupied BW Measurement On/Off
256
(Highest byte)
257
258
(Higher byte)
259
(Higher byte)
260
261
(Highest byte)
255
