Anritsu Spectrum Master MS2711D Programming Manual page 51

281) Status Byte 7
(LSB)
282) Reference Level Offset
283) Reference Level Offset
284) Reference Level Offset
285) Reference Level Offset (Lowest byte)
286) External Reference Frequency
287) Signal Standard
288) Signal Standard (Lower byte)
289) Channel Selection
290) Channel Selection (Lower byte)
291) Interference Analysis Cellular Standard
292) Interference Analysis Estimated Bandwidth (Highest byte)
293) Interference Analysis Estimated Bandwidth
294) Interference Analysis Estimated Bandwidth
295) Interference Analysis Estimated Bandwidth (Lowest byte)
296) Interference Analysis Frequency
297) Interference Analysis Frequency
298) Interference Analysis Frequency
299) Interference Analysis Frequency (Lowest byte)
300-303) Reserved
304) Trigger Type
305) Trigger Position (0 – 100%)
306) Min Sweep Time (in μs) (Highest byte)
307) Min Sweep Time (in μs)
308) Min Sweep Time (in μs)
309) Min Sweep Time (in μs) (Lowest byte)
310) Video Trigger Level
311) Video Trigger Level
312) Video Trigger Level
313) Video Trigger Level (Lowest byte)
314) Status Byte 8 (0b = Off, 1b = On)
(LSB)
315) Impedance (00h = 50Ω, 0Ah = 75Ω Anritsu Adapter, 0Ch = 75Ω Other Adapter)
316) Impedance Loss
317) Impedance Loss (Lower byte)
318) Frequency Scale Factor
186
Value sent as (Value in dBm * 1000 ) + 270,000
187
byte in MHz (i.e. 20 = 20MHz)
188
Index into Standard List (use control byte #89 to retrieve the ASCII string name). "No Standard" sent as FFFEh.
189
"No Channel" is sent as FFFEh.
190
4 Standards – 00h = 1250kHZ CDMA, 01h = GSM, 02h = TDMA, 03h = AMPS, 04h = Unknown FFh =
Interference Analysis Measurement OFF
191
Scaled by Frequency Scale Factor (bytes 318-319)
192
Trigger Type – 00h = Single, 01h = Free Run, 02h = Video, 03h = External
193
Value sent as (Value in dBm * 1000 ) + 270,000
194
Value sent as (value in dB * 1000), valid values are 0 to 20 dB
195
In number of Hz
50
bits 0-6: Number of Sweeps to Average (1-25, 1 implies averaging OFF)
bit 7 : Not Used
186
(Highest byte)
187
188
(Higher byte)
189
(Higher byte)
191
(Highest byte)
192
193
(Highest byte)
bits 0-1: Trace Math Operation (00b = A only, 01b = A-B, 10b = A+B)
bit 2: Max Hold On/Off
bit 3: Min Hold On/Off
bit 4: Transmission Calibration Status (Option 21 Only)
bit 5: Bias Tee On/Off (Option 10 Only)
bit 6: Occupied BW Measurement On/Off
bit 7: Not Used
194
(Higher byte)
195
(Higher byte)
190
