Anritsu Spectrum Master MS2711D Programming Manual page 39

294) Status Byte 3: (0b = Off, 1b = On)
(LSB)
sampling mode)
295) Status Byte 4
(0b = Off/Beep if data is BELOW line, 1b = On/Beep if data is ABOVE line)
(LSB)
296) Status Byte 5
( 0b = Off/Beep if data is below line, 1b = On/Beep if data is above line)
(LSB)
297) Status Byte 6
(0b = Off/Beep if data is BELOW line, 1b = On/Beep if data is ABOVE line)
(LSB)
298) Status Byte 7
(LSB)
299) Reference Level Offset
300) Reference Level Offset
301) Reference Level Offset
302) Reference Level Offset (Lowest byte)
303) External Reference Frequency
109
For bits 2, 1 and 0 ("X" is "don't care): 0X0=no limit, 1X0=single limit, 0X1=multiple limit, 1X1=multiple limit.
110
Upper limits always trigger an error beep if data is ABOVE the limit segment, for example, this bit is always 1b.
111
Lower limits always trigger an error beep if data is BELOW the limit segment, for example, this bit is always 0b.
112
Value sent as ( value in dBm * 1000 ) + 270,000
38
bit 4 : Pre Amp Mode (0b = Manual, 1b = Auto)
bit 5 : Pre Amp Status On/Off
bit 6 : Dynamic Attenuation On/Off
bit 7 : Normalization On/Off
bit 0 : Antenna Factor Correction On/Off
bits 1-2 : Detection alg (00b = pos. peak 01b = RMS average 10b = neg. peak 11b =
bits 3-4 : Amplitude Units (Log) - (00b = dBm 01b = dBV 10b = dBmV 11b = dBuV)
(Linear) – (00b = Watts 01b = Volts)
bit 5 : Channel Power On/Off
bit 6 : Adjacent Channel Power On/Off
bit 7 : Units Type (0b = Log 1b = Linear)
109
bit 0 : Limit Type (0b = Single, 1b = Multiple)
bit 1 : Not Used
bit 2 : Single Limit On/Off
bit 3 : Single Limit Beep Level ABOVE/BELOW
bit 4 : Multiple Limit Upper Segment 1 Status On/Off
bit 5 : Multiple Limit Upper Segment 1 Beep Level ABOVE/BELOW
bit 6 : Multiple Limit Upper Segment 2 Status On/Off
bit 7 : Multiple Limit Upper Segment 2 Beep Level ABOVE/BELOW
bit 0 : Multiple Limit Upper Segment 3 Status On/Off
bit 1 : Multiple Limit Upper Segment 3 Beep Level ABOVE/BELOW
bit 2 : Multiple Limit Upper Segment 4 Status On/Off
bit 3 : Multiple Limit Upper Segment 4 Beep Level ABOVE/BELOW
bit 4 : Multiple Limit Upper Segment 5 Status On/Off
bit 5 : Multiple Limit Upper Segment 5 Beep Level ABOVE/BELOW
bit 6 : Multiple Limit Lower Segment 1 Status On/Off
bit 7 : Multiple Limit Lower Segment 1 Beep Level ABOVE/BELOW
bit 0 : Multiple Limit Lower Segment 2 Status On/Off
bit 1 : Multiple Limit Lower Segment 2 Beep Level ABOVE/BELOW
bit 2 : Multiple Limit Lower Segment 3 Status On/Off
bit 3 : Multiple Limit Lower Segment 3 Beep Level ABOVE/BELOW
bit 4 : Multiple Limit Lower Segment 4 Status On/Off
bit 5 : Multiple Limit Lower Segment 4 Beep Level ABOVE/BELOW
bit 6 : Multiple Limit Lower Segment 5 Status On/Off
bit 7 : Multiple Limit Lower Segment 5 Beep Level ABOVE/BELOW
bits 0-6: Number of sweeps to average (1-25, 1 implies averaging OFF)
bit 7: Not Used
112
(Highest byte)
113
110
111
