59)
Multiple Upper Limit 1 End X (Frequency in Hz) (Lowest byte)
60)
Multiple Upper Limit 1 End Y (Power Level) (Highest byte)
61)
Multiple Upper Limit 1 End Y (Power Level)
62)
Multiple Upper Limit 1 End Y (Power Level)
63)
Multiple Upper Limit 1 End Y (Power Level) (Lowest byte)
64-207) Multiple Upper Limits 2-5, Multiple Lower Limits 1-5 (see bytes 48-63 for format)
208)
RBW Setting
209)
RBW Setting
210)
RBW Setting
211)
RBW Setting (Lowest byte)
212)
VBW Setting
213)
VBW Setting
214)
VBW Setting
215)
VBW Setting (Lowest byte)
216)
OCC BW Method (00h = % of power, 01h = dB down)
217)
OCC BW % Value (0-99) (Highest byte)
218)
OCC BW % Value (0-99)
219)
OCC BW % Value (0-99)
220)
OCC BW % Value (0-99) (Lowest byte)
221)
OCC BW dBc (0-120) (Highest byte)
222)
OCC BW dBc (0-120)
223)
OCC BW dBc (0-120)
224)
OCC BW dBc (0-120) (Lowest byte)
225)
Attentuation
226)
Attentuation
227)
Attentuation
228)
Attentuation (Lowest byte)
229)
Antenna Index (0-14)
230-245) Antenna Name (16 bytes in ASCII)
246)
AM/FM Demod Type (00h = FM-Wide Band, 01h = FM-Narrow Band, 02h = AM, 03h =
SSB/CW)
247)
AM/FM Demod Volume (00h = min, FFh = max)
248)
Reference Level Offset
249)
Reference Level Offset
250)
Reference Level Offset
251)
Reference Level Offset (Lowest byte)
252)
Impedance
253)
Impedance Loss
254)
Impedance Loss
255)
Impedance Loss
256)
Impedance Loss (Lowest byte)
257)
N/A
258)
N/A
259)
N/A
260)
N/A
261)
N/A
262)
N/A
263)
N/A
18
RBW: 00h = 10 kHz, 01h = 30 kHz, 02h = 100 kHz, 03h = 1 MHz
19
VBW: 00h = 100 Hz, 01h = 300 Hz, 02h = 1 kHz, 03h = 3 kHz, 04h = 10 kHz, 05h = 30 kHz, 06h = 100 kHz, 07h
= 300 kHz
20
Attenuation: 00h = 0 dB, 01h = 10 dB, 02h = 20 dB, 03h = 30 dB, 04h = 40 dB, 05h = 50 dB
21
"value" sent as (value in dBm * 1,000) + 270,000
22
Impedance Adapter: 00h = 50 Ω, 0Ah = 75 Ω, adapter 12N50-75B, 0Ch = 75 Ω, other adapter offset
23
"value" sent as (value in dBm * 1,000) + 270,000
18
18
(Highest byte)
19
(Highest byte)
20
(Highest byte)
21
(Highest byte)
22
23
(Highest byte)
