278) Video Trigger Level
279) Video Trigger Level (Lowest byte)
280) Status Byte 8
(LSB) bit 0: Limit Beep Output (Option 86 Only) (00h = Internal Speaker, 01h = External)
281) Status Byte 9
(LSB) bits 0-6: Number of sweeps to average (1-25, 1 implies averaging OFF)
282) Status Byte 10: (0b = Off, 1b = On)
(LSB) bits 0-1: Trace Math Operation (00b = A only, 01b = A-B, 10b = A+B)
283) Impedance (00h = 50Ω, 10h = 75Ω Anritsu Adapter, 12h = 75Ω Other Adapter)
284) Impedance Loss
285) Impedance Loss (Lower byte)
286) AM/FM Demod Type
287) AM/FM Demod Status (01h = On, 00h = Off)
288) AM/FM Demod Volume (0 to 100)
289) AM/FM Demod Frequency
290) AM/FM Demod Frequency
291) AM/FM Demod Frequency
292) AM/FM Demod Frequency (Lowest byte)
293) AM/FM Demod Time (in ms) (Highest byte)
294) AM/FM Demod Time (in ms)
295) AM/FM Demod Time (in ms)
296) AM/FM Demod Time (in ms) (Lowest byte)
297) SSB BFO Offset
298) SSB BFO Offset
299) SSB BFO Offset
300) SSB BFO Offset (Lowest byte)
301) Frequency Scale Factor
302) Frequency Scale Factor (Lower byte)
303) Frequency Range Minimum
304) Frequency Range Minimum
305) Frequency Range Minimum
306) Frequency Range Minimum (Lowest byte)
307) Frequency Range Maximum
308) Frequency Range Maximum
309) Frequency Range Maximum
310) Frequency Range Maximum (Lowest byte)
311) Marker Type
312) Channel Power Int BW
342
Value sent as (value in dB * 1000), valid values are 0 to 20 dB
343
AM/FM Demod Type: 00h = FM-Wide Band, 01h = FM-Narrow Band, 02h = AM, 03h = SSB Lower, 04h =
SSB Upper
344
Scaled by Frequency Scale Factor (bytes 301-302)
345
Value sent as ((value in Hz) – 10,000)
346
In number of Hz
347
Scaled by Frequency Scale Factor (bytes 301-302)
348
Scaled by Frequency Scale Factor (bytes 301-302)
349
00h = Regular Marker, 01h = Noise Marker
350
Scaled by Frequency Scale Factor (bytes 301-302)
76
bits 1-7: Not Used
bit 7: Not Used
bit 2: Max Hold On/Off
bit 3: Min Hold On/Off
bit 4: View B On/Off
bit 5: External Reference Frequency On/Off
bits 6-7: Not Used
342
(Higher byte)
343
344
(Highest byte)
345
(Highest byte)
346
(Higher byte)
347
(Highest byte)
348
(Highest byte)
349
350
(Highest byte)
