3) Memory Check (01h: Pass, 00h: Fail)
4) RTC Voltage Check (01h: Pass, 00h: Fail)
5) Power Voltage in 1/10ths of a Volt (e.g. 124 = 12.4 Volts) (Higher byte)
6) Power Voltage in 1/10ths of a Volt (e.g. 124 = 12.4 Volts) (Lower byte)
7) VNA Lock Failure Counter (Higher byte)
8) VNA Lock Failure Counter (Lower byte)
9) VNA Integrator Failure Counter (Higher byte)
10) VNA Integrator Failure Counter (Lower byte)
11) SPA LO Failure Counter (Higher byte)
12) SPA LO Failure Counter (Lower byte)
13) H/W Config - Mother Board ID
14) H/W Config - SPA Board ID
15) H/W Config - T1E1 Board ID
16) H/W Config - PLD1 ID
17) H/W Config - PLD2 ID
18) H/W Config – T1E1 COLD ID
19) VNA PLL Lock Failure Test - Status (01h: Pass, 00h: Fail)
20) VNA PLL Lock Failure Test - Failed data point # (Ignore this byte if the Lock Fail Test Status was
Pass)
21) VNA PLL Lock Failure Test - Failed PLL # (Ignore this byte if the Lock Fail Test Status was Pass)
22) VNA Integration Test - Status (01h: Pass, 00h: Fail)
23) VNA Integration Test - Failed data point # (Ignore this byte if the Integration Test Status was Pass)
24) VNA Integration Test - Reserved
25) SPA LO Test - Status (01h: Pass, 00h: Fail, FFh: SPA board not installed)
26) SPA LO Test - Failed data point #
27) SPA LO Test - Failed LO #
28) Module PLD Version
29) Module Attached
30) Module Lock (01h = Locked, 00h = Not Locked)
31) Module Lock Fail Counter (Higher byte)
32) Module Lock Fail Counter (Lower byte)
33) End of Data (FFh)
Trigger Sweep – Control Word (AA30h)
Description: Causes the Spectrum Master to perform a sweep if it is in single sweep mode.
This command works only when the Spectrum Master is NOT in remote mode. Send this command, receive the
"Operation Complete Byte" and then wait for the "Sweep Complete Byte" to signify the end of the sweep.
Note: The "Sweep Complete Byte" is not returned unless serial echo status is turned on using command #10.
Bytes to Follow: 0 bytes
Spectrum Master Returns: 2 bytes
1) 255 (FFh) Operation Complete Byte (when the command is received)
2) 192 (C0h) Sweep Complete Byte (at the end of the sweep)
