Anritsu Spectrum Master MS2711D Programming Manual page 40

304) Signal Standard
305) Signal Standard (Lower byte)
306) Channel Selection
307) Channel Selection (Lower byte)
308) Interference Analysis Cellular Standard
309) Interference Analysis Estimated Bandwidth (Highest byte)
310) Interference Analysis Estimated Bandwidth
311) Interference Analysis Estimated Bandwidth
312) Interference Analysis Estimated Bandwidth (Lowest byte)
313) Interference Analysis Frequency
314) Interference Analysis Frequency
315) Interference Analysis Frequency
316) Interference Analysis Frequency (Lowest byte)
317-320) Reserved
321) Trigger Type
322) Trigger Position (0 – 100%)
323) Min Sweep Time (in μs) (Highest byte)
324) Min Sweep Time (in μs)
325) Min Sweep Time (in μs)
326) Min Sweep Time (in μs) (Lowest byte)
327) Video Trigger Level
328) Video Trigger Level
329) Video Trigger Level
330) Video Trigger Level (Lowest byte)
331) Status Byte 8 (0b = Off, 1b = On)
(LSB)
332) Impedance (00h = 50Ω, 0Ah = 75Ω Anritsu Adapter, 0Ch = 75Ω Other Adapter)
333) Impedance Loss
334) Impedance Loss (Lower byte)
335) Frequency Scale Factor
336) Frequency Scale Factor (Lower byte)
337) Frequency Range Minimum
338) Frequency Range Minimum
339) Frequency Range Minimum
340) Frequency Range Minimum (Lowest byte)
341) Frequency Range Maximum
342) Frequency Range Maximum
113
1 byte in MHz (i.e. 20 = 20MHz)
114
Index into Standard List (use control byte #89 to retrieve the ASCII string name). "No Standard" sent as FFFEh
115
"No Channel" is sent as FFFEh
116
4 Standards – 00h = 1250kHZ CDMA, 01h = GSM, 02h = TDMA, 03h = AMPS, 04h = Unknown, FFh =
Interference Analysis Measurement OFF
117
Scaled by Frequency Scale Factor (bytes 335-336)
118
Trigger Type – 00h = Single, 01h = Free Run, 02h = Video, 03h = External
119
Value sent as ( value in dBm * 1000 ) + 270,000
120
Value sent as (value in dB * 1000), valid values are 0 to 20 dB
121
In number of Hz
122
Scaled by Frequency Scale Factor
123
Scaled by Frequency Scale Factor
39
114
(Higher byte)
115
(Higher byte)
117
(Highest byte)
118
119
(Highest byte)
bits 0-1: Trace Math Operation (00b = A only, 01b = A-B, 10b = A+B)
bit 2: Max Hold On/Off
bit 3: Min Hold On/Off
bit 4: Transmission Calibration On/Off (Option 21 Only)
bit 5: Bias Tee On/Off (Option 10 Only)
bit 6: Occupied BW Measurement On/Off
bit 7: Not Used
120
(Higher byte)
121
(Higher byte)
122
(Highest byte)
123
(Highest byte)
116
