Retrieve Power in CW GENERATOR MODE - CODE WORD(A802h)

Description: This command tells the Cell Master to return the power value in dBM. The value returned will be an
unsigned. The values under -0 dB will be made positive and multiplied by 1000. e.g. -73.12dBm will become 731200
Bytes to Follow: 0 bytes
Cell Master Returns: 5 bytes
1.) highest byte of the power value
2.) second byte of the power value
3.) third byte of the power value
4.) lowest byte of the power value
5.) 255 (FFh) Operation Complete Byte
Remote Self Test – Control Word (AA15h)
Description: Trigger the equivalent of a "key press" selftest.
Note: The response bytes will not all be returned immediately. The first 12 will be returned, then there will be a
slight delay before the next 14 are returned, then a final delay while the T1/E1 selftest is performed and the final 12
bytes are returned.
Bytes to Follow: 0 bytes
Spectrum Master Returns:
No Options or Option 10 and/or Option 29: 22 bytes
1) Temperature in 1/10th of degree Celsius (e.g. 362 = 36.2
2) Temperature in 1/10th of degree Celsius (e.g. 362 = 36.2
3) Memory Check (01h: Pass, 00h: Fail)
4) RTC Voltage Check (01h: Pass, 00h: Fail)
5) Power Voltage in 1/10ths of a Volt (e.g. 124 = 12.4 Volts) (Higher byte)
6) Power Voltage in 1/10ths of a Volt (e.g. 124 = 12.4 Volts) (Lower byte)
7) Reserved
8) Reserved
9) Reserved
10) Reserved
11) SPA LO Failure Counter (Higher byte)
12) SPA LO Failure Counter (Lower byte)
13) H/W Config - Mother Board ID
14) H/W Config - SPA Board ID
15) H/W Config - T1E1 Board ID
16) H/W Config - PLD1 ID
17) H/W Config - PLD2 ID
18) H/W Config – T1E1 COLD ID
19) SPA LO Test - Status (01h: Pass, 00h: Fail, FFh: SPA board not installed)
20) SPA LO Test - Failed data point #
21) SPA LO Test - Failed LO #
22) End of Data (FFh)
Option 21 (+ Option 10 and/or Option 29): 28 bytes
1) Temperature in 1/10th of degree Celsius (e.g. 362 = 36.2
2) Temperature in 1/10th of degree Celsius (e.g. 362 = 36.2
3) Memory Check (01h: Pass, 00h: Fail)
4) RTC Voltage Check (01h: Pass, 00h: Fail)
5) Power Voltage in 1/10ths of a Volt (e.g. 124 = 12.4 Volts) (Higher byte)
6) Power Voltage in 1/10ths of a Volt (e.g. 124 = 12.4 Volts) (Lower byte)
