58) Frequency Range Minimum
59) Frequency Range Minimum (Lowest byte)
60) Frequency Range Maximum
61) Frequency Range Maximum
62) Frequency Range Maximum
63) Frequency Range Maximum (Lowest byte)
64) Zero Status (00h = Off, 01h = On)
314
65) Zero Value
66) Zero Value
67) Zero Value
68) Zero Value (Lowest byte)
69-120) Not Used
Upload Setup – Control Byte #66 (42h)
Description: Returns parameters associated with the specified setup number. Since different modes have different
numbers of setup locations available, the command requires the mode be specified as well as the setup number.
Setup numbers as follows:
0 = Run time setup
1 – 10 = Saved setups for Spectrum Analyzer/Transmission Measurement modes
1 – 5 = Saved setups for Power Meter mode (Option 29 Only)
Bytes to Follow: 2 bytes
For All Modes:
1) Number of Following Bytes (Higher byte)
2) Number of Following Bytes (Lower byte)
3) Measurement Mode
4) Setup Number in which to store setup
5-20) Not Used
For Spectrum Analyzer Mode:
21) Spectrum Analyzer Start Frequency
22) Spectrum Analyzer Start Frequency
23) Spectrum Analyzer Start Frequency
24) Spectrum Analyzer Start Frequency (Lowest byte)
25) Spectrum Analyzer Stop Frequency
26) Spectrum Analyzer Stop Frequency
27) Spectrum Analyzer Stop Frequency
28) Spectrum Analyzer Stop Frequency (Lowest byte)
29) Spectrum Analyzer Center Frequency
30) Spectrum Analyzer Center Frequency
31) Spectrum Analyzer Center Frequency
32) Spectrum Analyzer Center Frequency (Lowest byte)
33) Spectrum Analyzer Frequency Span
34) Spectrum Analyzer Frequency Span
35) Spectrum Analyzer Frequency Span
36) Spectrum Analyzer Frequency Span (Lowest byte)
313
Scaled by Frequency Scale Factor
314
Value sent as ((value in dBm * 1000) + 100)
315
Refer to Control Byte #3 "Select Measurement Mode" for valid measurement modes.
316
Scaled by Frequency Scale Factor (bytes 301-302)
317
Scaled by Frequency Scale Factor (bytes 301-302)
318
Scaled by Frequency Scale Factor (bytes 301-302)
319
Scaled by Frequency Scale Factor (bytes 301-302)
72
313
(Highest byte)
(Highest byte)
315
316
(Highest byte)
317
(Highest byte)
318
319
(Highest byte)
(Highest byte)
