Anritsu Spectrum Master MS2711D Programming Manual page 37

21-30) Date in String Format (mm/dd/yyyy)
31-38) Time in String Format (hh:mm:ss)
39-54) Reference number stamp (16 bytes in ASCII)
55-56) # data points (130, 259 or 517 or 401 or 100)
For Spectrum Analyzer Mode:
57) Start Frequency
58) Start Frequency
59) Start Frequency
60) Start Frequency (Lowest byte)
61) Stop Frequency
62) Stop Frequency
63) Stop Frequency
64) Stop Frequency (Lowest byte)
65) Center Frequency
66) Center Frequency
67) Center Frequency
68) Center Frequency (Lowest byte)
69) Frequency Span
70) Frequency Span
71) Frequency Span
72) Frequency Span (Lowest byte)
73) Minimum Frequency Step Size (Highest byte)
74) Minimum Frequency Step Size
75) Minimum Frequency Step Size
76) Minimum Frequency Step Size (Lowest byte)
77) Ref Level
78) Ref Level
79) Ref Level
80) Ref Level (Lowest byte)
81) Scale per div
82) Scale per div
83) Scale per div
84) Scale per div (Lowest byte)
85) Frequency Marker 1
86) Frequency Marker 1 (Lower byte)
87) Frequency Marker 2 (Higher byte)
88) Frequency Marker 2 (Lower byte)
89) Frequency Marker 3 (Higher byte)
90) Frequency Marker 3 (Lower byte)
91) Frequency Marker 4 (Higher byte)
92) Frequency Marker 4 (Lower byte)
93) Frequency Marker 5 (Higher byte)
94) Frequency Marker 5 (Lower byte)
95) Frequency Marker 6 (Higher byte)
96) Frequency Marker 6 (Lower byte)
97) Single Limit
95
Scaled by Frequency Scale Factor (bytes 335-336)
96
Scaled by Frequency Scale Factor (bytes 335-336)
97
Scaled by Frequency Scale Factor (bytes 335-336)
98
Scaled by Frequency Scale Factor (bytes 335-336)
99
Value sent as ( Value in dBm * 1000 ) + 270,000
100
Value sent as ( Value * 1000 )
101
Value sent as data point on display. Freq = ( Point * Span / ( Total Data Points – 1 ) ) + Start Freq
102
Value sent as ( Value in dBm * 1000 ) + 270,000
36
95
(Highest byte)
96
(Highest byte)
97
(Highest byte)
98
(Highest byte)
99
(Highest byte)
100
(Highest byte)
101
(Higher byte)
102
(Highest byte)
