Anritsu Spectrum Master MS2711D Programming Manual page 76

254) Status Byte 5 : ( 0b = Off/Beep if data is BELOW line ,
(LSB)
255) Status Byte 6: (0b = Off, 1b = On)
(LSB)
256) Status Byte 7: (0b = Off, 1b = On)
(LSB) bit 0: Interference Analysis On/Off
257) Reference Level Offset
258) Reference Level Offset
259) Reference Level Offset
260) Reference Level Offset (Lowest byte)
261) External Reference Frequency
262) Signal Standard
263) Signal Standard (Lower byte)
264) Channel Selection
265) Channel Selection (Lower byte)
266) Trigger Type
267) Interference Analysis Frequency
268) Interference Analysis Frequency
269) Interference Analysis Frequency
270) Interference Analysis Frequency (Lowest byte)
271) Trigger Position (0 – 100%)
272) Min Sweep Time (in μs) (Highest byte)
273) Min Sweep Time (in μs)
274) Min Sweep Time (in μs)
275) Min Sweep Time (in μs) (Lowest byte)
276) Video Trigger Level
277) Video Trigger Level
335
Value sent as (value in dBm * 1000) + 270,000
336
1 byte in MHz (i.e. 20 = 20MHz)
337
Index into Standard List (use control byte #89 to retrieve the ASCII string name). "No Standard" sent as FFFEh
338
"No Channel" is sent as FFFEh
339
Trigger Type – 00h = Single, 01h = Free Run, 02h = Video, 03h = External
340
Scaled by Frequency Scale Factor (bytes 301-302)
341
Value sent as ( value in dBm * 1000 ) + 270,000
75
1b = On/Beep if data is ABOVE line)
bit 0 : SPA Multiple Limit Lower Segment 2 Status On/Off
bit 1 : SPA Multiple Limit Lower Segment 2 Beep Level ABOVE/BELOW
bit 2 : SPA Multiple Limit Lower Segment 3 Status On/Off
bit 3 : SPA Multiple Limit Lower Segment 3 Beep Level ABOVE/BELOW
bit 4 : SPA Multiple Limit Lower Segment 4 Status On/Off
bit 5 : SPA Multiple Limit Lower Segment 4 Beep Level ABOVE/BELOW
bit 6 : SPA Multiple Limit Lower Segment 5 Status On/Off
bit 7 : SPA Multiple Limit Lower Segment 5 Beep Level ABOVE/BELOW
bit 0 : Antenna Factors Correction On/Off
bit 1 : Bias Tee On/Off (Option 10)
bit 2 : Amplitude Units (Linear) – 00b = Watts 01b = Volts
bits 3-4 : Amplitude Units (Log) - 00b = dBm 01b = dBV 10b = dBmV 11b = dBuV
bits 5-6 : Detection Alg (00b = pos. peak 01b = RMS Averaging 10b = neg. peak 11b =
Sampling Mode)
bit 7 : Units Type (0b = Log 1b = Linear)
bit 1: C/I Measurement On/Off
bit 2: RBW Coupling (1b = Auto, 0b = Manual)
bit 3: VBW Coupling (1b = Auto, 0b = Manual)
bit 4: Attenuation Coupling (1b = Auto, 0b = Manual)
bit 5: Channel Power On/Off
bit 6: Adjacent Channel Power On/Off
bit 7: Occupied BW Measurement On/Off
335
(Highest byte)
336
337
(Higher byte)
338
(Higher byte)
339
340
341
(Highest byte)
(Highest byte)
