Anritsu Spectrum Master MS2711D Programming Manual page 78

313) Channel Power Int BW
314) Channel Power Int BW
315) Channel Power Int BW (Lowest byte)
316) ACPR Main Channel BW
317) ACPR Main Channel BW
318) ACPR Main Channel BW
319) ACPR Main Channel BW (Lowest byte)
320) ACPR Adjacent Channel BW
321) ACPR Adjacent Channel BW
322) ACPR Adjacent Channel BW
323) ACPR Adjacent Channel BW (Lowest byte)
324) ACPR Channel Spacing
325) ACPR Channel Spacing
326) ACPR Channel Spacing
327) ACPR Channel Spacing (Lowest byte)
328) Interference Analysis Cell Std
329) Interference Analysis Est. BW
330) Interference Analysis Est. BW
331) Interference Analysis Est. BW
332) Interference Analysis Est. BW (Lowest byte)
333) Trace B Trace Id
334-500) Not Used
For Transmission Mode (Option 21 Only):
21) Start Frequency
22) Start Frequency
23) Start Frequency
24) Start Frequency (Lowest byte)
25) Stop Frequency
26) Stop Frequency
27) Stop Frequency
28) Stop Frequency (Lowest byte)
29) Center Frequency
30) Center Frequency
31) Center Frequency
32) Center Frequency (Lowest byte)
33) Frequency Span
34) Frequency Span
35) Frequency Span
36) Frequency Span (Lowest byte)
37) Ref Level (Highest byte)
38) Ref Level
39) Ref Level
351
Scaled by Frequency Scale Factor (bytes 301-302)
352
Scaled by Frequency Scale Factor (bytes 301-302)
353
Scaled by Frequency Scale Factor (bytes 301-302)
354
4 Standards – 00h = 1250 kHZ CDMA, 01h = GSM, 02h = TDMA, 03h = AMPS, 04h = Unknown, FFh =
Interference Analysis Measurement OFF
355
Frequency in Hz
356
FFh indicates to trace selected
357
Scaled by Frequency Scale Factor (bytes 244-245)
358
Scaled by Frequency Scale Factor (bytes 244-245)
359
Scaled by Frequency Scale Factor (bytes 244-245)
360
Scaled by Frequency Scale Factor (bytes 244-245)
361
Value sent as (value in dBm * 1000) + 270,000)
77
351
(Highest byte)
352
(Highest byte)
353
(Highest byte)
354
355
(Highest byte)
356
357
(Highest byte)
358
(Highest byte)
359
(Highest byte)
360
(Highest byte)
361
