Enter Remote Mode – Control Byte #69 (45h)
Description: Enter remote mode at the end of a sweep then send model number and firmware version to the
computer.
The computer sends Enter Remote mode byte #69 (45h) to the Spectrum Master and waits for response.
Since the Spectrum Master polls its serial port buffer at the end of each sweep, the computer must wait until the
Spectrum Master sends the return bytes before sending a new control byte. Otherwise, the new control byte
overwrites the old one (saying enter remote) and the Spectrum Master does not respond as expected.
Once in remote mode, the Spectrum Master stops sweeping. A Remote Mode Indicator appears on the LCD.
The Spectrum Master sends its model and software version numbers to the computer. The Spectrum Master is now
able to take multiple control bytes. It waits for the next control byte.
Bytes to Follow: 0 bytes
Spectrum Master Returns: 13 bytes
1-2) Model # (unsigned integer, 16h for Spectrum Master MS2711D)
3-9) Extended Model # (7 bytes in ASCII)
10-13) Software Version - 4 bytes (ASCII)
Enter Remote Mode Immediately – Control Byte #70 (46h)
Description: Enter remote mode in the middle of a sweep, then send the model number and firmware version to the
computer.
The computer sends Enter Remote Mode Immediately byte #70 (46h) to the Spectrum Master and waits for a
response. This control byte causes the unit to enter remote mode immediately. Note that this could result in
incomplete sweep data. Use control byte #69 if complete data is required.
Once in remote mode, the Spectrum Master stops sweeping. A Remote Mode Indicator appears on the LCD.
The Spectrum Master sends its model and software version numbers to the computer. The Spectrum Master is now
able to take multiple control bytes. It waits for the next control byte.
Bytes to Follow: 0 bytes
Spectrum Master Returns: 13 bytes
1-2) Model # (unsigned integer, 16h for Spectrum Master MS2711D)
3-9) Extended Model # (7 bytes in ASCII)
10-13) Software Version (4 bytes in ASCII)
