Spectrogram: Get Trace Name – Control Word (A724h)
This command is available only with option 25.
Description: Get the Trace names saved in five spectrogram memory slots. The name is composed with Time &
Date when the trace is saved. If the memory slot is empty, the date field is set with "--/--/----" and the time field is
set with "--:--:--".
Bytes to Follow: 0 bytes
Cell Master Returns:
When control word is received correctly: 101 bytes
1-2) Index of trace (from 0 to 4)
3-12) Date of save in ASCII string, format: "--/--/----"
13-20) Time of save in ASCII string, format: "--:--:--"
21-100) Repeat the information of 1) to 20) four times
101) FFh
When error occurs: 1 byte
224 (E0h) Parameter Error: Module not attached
238 (EEh) Time Out Error
