321) Status Byte 7
(LSB)
322) Status Byte 8: (0b = Off, 1b = On
(LSB)
YYYYMMDD)
323) N/A
324) N/A
325-350) Not Used
351-1950) Sweep Data
Spectrum Master Returns (For invalid sweeps/empty stored sweep locations): 11 bytes
1-2) Number of following bytes (9 bytes for invalid sweep recall)
3-4) Model # (unsigned integer, 16h for Spectrum Master model MS2711D)
5-11) Extended Model # (7 bytes in ASCII)
Spectrum Master Returns (Invalid sweep location): 1 byte
1) 224 Parameter Error: Invalid sweep location
Save System Setup – Control Byte #18 (12h)
Description: Saves current system setup parameters to a specific setup store location.
The Spectrum Master saves all parameters described in Query System Status - Control Byte #29 (1Dh), (except
Serial Port Echo Status) to the specified store location. Store location 0 is the run-time setup of the Spectrum
Master. It holds the power-on defaults of the Spectrum Master.
Bytes to Follow: 1 byte
1) Location to save system setup parameters:
0 – 10 for Spectrum Analyzer and Transmission Modes (Option 21 Only)
0 – 5 for Power Meter Mode (Option 29 Only)
0 – 5 for T1/E1 Modes (Option 50 Only)
Spectrum Master Returns: 1 byte
1) 255 (FFh) Operation Complete Byte
224 (E0h) Parameter Error : Invalid store location
238 (EEh) Time-out Error
15
bit 5 : Multiple Limit Lower Segment 4 Limit Level UPPER / LOWER
bit 6 : Multiple Limit Lower Segment 5 Status On/Off
bit 7 : Multiple Limit Lower Segment 5 Limit Level UPPER / LOWER
bits 0-6 : Number of Sweeps to Average (1-25, 1 implies averaging Off)
bit 7 : Reserved
bit 0 : Preamp On/Off
bit 1 : Normalization On/Off
bit 2 : Bias Tee On/Off
bit 3 : Scale Type (0b = Log, 1b = Linear)
bit 4 : Linear Units (0b = Watts, 1b = Volts)
bits 5-7 : Date Format (000b = MMDDYYYY, 001b = DDMMYYYY, 010b =
(400 points * 4 bytes/point = 1600 bytes)
4 bytes for each data point
1. dBm 2 (Highest byte)
2. dBm
3. dBm
4. dBm (Lowest byte)
