The Sweep Data Echo Mode allows run-time handshaking between the Spectrum Master and computer by doing the
following:
1) Enter remote mode. Set Sweep Data Echo Mode On. Exit remote mode.
2) The Spectrum Master sweeps once and then sends the Sweep Complete Byte.
3) After you receive it: Recall sweep 0 (last sweep trace in RAM).
4) If using auto triggering, repeat steps 2-3. If using manual triggering, go to step 5.
5) Send Sweep Triggering Byte #48 (30h) and wait for the next sweep cycle.
6) Repeat steps 2-5.
Note: To execute commands other than #33, you must use the traditional Enter Remote, Send Commands, Exit
Remote communication sequence.
Bytes to Follow: 2 bytes
1) Sweep Data Echo Status
00h : Off
01h : On
2) Next Sweep Trigger
00h : Manual
01h : Automatic
Spectrum Master Returns: 1 byte
1) 255 (FFh) Operation Complete Byte
224 (E0h) Parameter Error : Invalid sweep data echo status
238 (EEh) Time-out Error
Check Battery Status – Control Byte #50 (32h)
Description: Return Smart Battery status.
Bytes to Follow: 0 bytes
Spectrum Master Returns: 17 bytes
1-2)
Battery Status flags ( Refer to Smart Battery Data Spec 5.1.2.1)
3-4)
State of Charge (unsigned integer 0 to 100(%)Full)
5-6)
Battery Voltage (unsigned integer 0 to 65535 in mV)
7-8)
Battery Current (signed integer -32,768 to +32,7687 mA, positive = Charging)
9-10)
Battery Average current (signed integer -32,768 to +32,7687 mA, positive = Charging)
11-12) Average time to empty (unsigned integer 0 to 65535 minute)
13-14) Battery Charge Cycle Count (unsigned integer 0 to 65535 cycles)
15-16) Battery Capacity at Full Charge in mA Hours (unsigned integer 0 to 65535 cycles)
17)
Unit under battery power (1 = YES; 0 = NO)
Note:
The Smart Battery Data Spec can be found at http://www.sbs-forum.org/specs/index.html
60
