Read Module Fail Counter – Control Word (A204h)
This command is available only with option 6.
Description: Returns the value of the module lock fail counter.
Bytes to Follow: 0 bytes
Spectrum Master Returns: 3 bytes (success) OR 1 byte (failure)
1) Fail Counter (Higher byte)
2) Fail Counter (Lower byte)
3) 255 (FFh) Operation Complete Byte
OR
1) 255 (FFh) Operation Complete Byte
224 (E0h) Parameter Error: Module not attached
238 (EEh) Time Out Error
Clear Module Fail Counter – Control Word (A205h)
This command is available only with option 6.
Description: Sets the module lock fail counter to 0.
Bytes to Follow: 0 bytes
Spectrum Master Returns: 1 byte
1) 255 (FFh) Operation Complete Byte
224 (E0h) Parameter Error: Module not attached
238 (EEh) Time Out Error
Perform Transmission Mode Calibration – Control Word (A301h)
This command is available only with option 21.
Description: Perform Transmission Mode Calibration.
Bytes to Follow: 0 bytes
Spectrum Master Returns: 1 byte
1) 255 (FFh) Operation Complete Byte
224 (E0h) Parameter Error: Invalid channel
238 (EEh) Time Out Error
Turn OFF Transmission Mode Calibration – Control Word (A302h)
This command is available only with option 21.
Description: Turn OFF Transmission Mode Calibration
Bytes to Follow: 0 bytes
Spectrum Master Returns: 1 byte
1)
255 (FFh) Operation Complete Byte
238 (EEh) Time Out Error
117
