101) Frequency Range Minimum (Lowest byte)
102) Frequency Range Maximum
103) Frequency Range Maximum
104) Frequency Range Maximum
105) Frequency Range Maximum (Lowest byte)
106 – 150) Not Used
151) Power Meter Reading
152) Power Meter Reading
153) Power Meter Reading
154) Power Meter Reading (Lowest byte)
155) Measure Offset Status (00h = Off, 01h = On)
For Channel Scanner Mode:
57) Reference Level (Highest Byte)
58) Reference Level
59) Reference Level
60) Reference Level (Lowest Byte)
61) Scale Division (Highest Byte)
62) Scale Division
63) Scale Division
64) Scale Division (Lowest Byte)
65) Start Frequency (Highest Byte)
66) Start Frequency
67) Start Frequency
68) Start Frequency (Lowest Byte)
69) Span Frequency (Highest Byte)
70) Span Frequency
71) Span Frequency
72) Span Frequency (Lowest Byte)
73) Channel Step (Highest Byte)
74) Channel Step (Lowest Byte)
75) Channel Frequency Step (Highest Byte)
76) Channel Frequency Step
77) Channel Frequency Step
78) Channel Frequency Step (Lowest Byte)
79) Number of Channels Displayed
80) External Reference Frequency
81) Display Type Channels or Frequencies
82) Display Type Graph or Text
83) Signal Standard (Highest Byte)
84) Signal Standard
85) Signal Standard
86) Signal Standard (Lowest Byte)
87-90) GPS Position – Latitude (long integer)
91-94) GPS Position – Longitude (long integer)
95-96) GPS Position – Altitude (short integer)
97) Start Channel (Highest Byte)
146
Scaled by Frequency Scale Factor
147
Power sent as (power in dBm * 1000). Use two's-complement method to decode negative power levels.
148
Frequency in MHz, OFF if 0
149
0 – Channel, 1 - Frequency
150
0 – Graph, 1 - Text
151
Signed long integer is used to represent latitude and longitude. Positive latitude means North hemisphere,
negative latitude means South hemisphere; Positive longitude means East hemisphere, negative longitude means
West hemisphere. Degree = int(abs(value)/1,000,000); Minute = (float)(abs(value)%1,000,000)/10,000
42
146
(Highest byte)
147
(Highest byte)
148
149
150
151
