Query Saved Setups – Control Byte #68 (44h)
Description: Returns a list of setups saved for the specified measurement mode. Modes that are stored in the same
table (i.e. Spectrum Analyzer and Transmission Measurement modes) will be returned by this command when either
mode is specified.
Frequency Scale Factor is defined as the number of Hz.
Start and Stop frequencies are sent scaled by the Frequency Scale Factor.
Bytes to Follow: 1 byte
1) Measurement Mode
Spectrum Master Returns:
For All Modes:
1) Number of Following Bytes (Higher byte)
2) Number of Following Bytes (Lower byte)
3) Number of Setups
For Each Setup:
1) Setup Number
2) Attributes
bit 0: Read Only Status (00h = Write-able, 01h = Read Only)
bits 1-7: Not Used
3) Measurement Mode
4) Cal Status (Transmission Mode Setup Only, 00h = Off, 01h = On)
5) Frequency Scale Factor (Higher byte)
6) Frequency Scale Factor (Lower byte)
7) Start Frequency (Highest byte)
8) Start Frequency
9) Start Frequency
10) Start Frequency (Lowest byte)
11) Stop Frequency (Highest byte)
12) Stop Frequency
13) Stop Frequency
14) Stop Frequency (Lowest byte)
15-20) Not Used
441
Refer to Control Byte #3 "Select Measurement Mode" for valid measurement modes.
442
Refer to Control Byte #3 "Select Measurement Mode" for valid measurement modes.
