OBSOLETE: Set Spectrum Analyzer Video Bandwidth – Control Byte #107 (6Bh)
This command exists for backward compatibility with the MS2711B. To access new video bandwidths use
Control Byte #142 (8Eh).
Description: Sets the video BW frequency for the Spectrum Analyzer.
Bytes to Follow: 1 byte
1) Video Bandwidth Index
00h – 100 Hz BW
01h – 300 Hz BW
02h – 1 kHz BW
03h – 3 kHz BW
04h – 10 kHz BW
05h – 30 kHz BW
06h – 100 kHz BW
07h – 300 kHz BW
Spectrum Master Returns: 1 byte
1) 255 (FFh) Operation Complete Byte
224 (E0h) Parameter Error: Invalid VBW Index
238 (EEh) Time Out Error
Set Spectrum Analyzer Sweep Mode – Control Byte #108 (6Ch)
Description: Enables or disables the Single Sweep Mode during Spectrum Analyzer mode of operation.
Single Sweep Mode activates once the Spectrum Master exits from the remote mode.
For Single Sweep Mode during Spectrum Master VNA modes of operation see control byte #11 (0Bh).
Bytes to Follow: 1 byte
1) Sweep Mode
00h – Single Sweep
01h – Continuous Sweep
02h – Video Trigger (span must be 0)
03h – External Trigger (span must be 0)
Spectrum Master Returns: 1 byte
1) 255 (FFh) Operation Complete Byte
224 (E0h) Parameter Error: Invalid Mode
238 (EEh) Time Out Error
Set Spectrum Analyzer Marker to Peak – Control Byte #109 (6Dh)
Description: Sets the specified marker to the peak value of the sweep.
Bytes to Follow: 1 byte
1) Marker Number (1-6)
Spectrum Master Returns: 1 byte
1) 255 (FFh) Operation Complete Byte
224 (E0h) Parameter Error: Invalid Marker Number
238 (EEh) Time Out Error
