Sun
Ultra
2 Series
™
™
Service Manual
The Network Is the Computer
™
Sun Microsystems Computer Company
2550 Garcia Avenue
Mountain View, CA 94043 USA
415 960-1300
fax 415 969-9131
Part No.: 802-2561-10
Revision A, May 1996
