3. Disassembly
This section describes the procedures required to exchange line replaceable units.
a.
Whenever a unit is replaced, mechanical and functional testing as described in Section
Mechanical & Functional Testing
b. It is recommended that the 3004-0055 F3Ci service tool kit be used to conduct
disassembly and reassembly procedures. The tool kit contains the following:
Pull-through for coil cable
•
Flat blade screwdriver
•
3mm hex key driver
•
2.5mm hex key driver
•
2mm hex key driver
•
T20 Torx driver
•
18mm spanner
•
13mm spanner
•
10mm spanner
•
3mm pin punch
•
Screwdriver Pozidrive No 1
•
Screwdriver Pozidrive No 2
•
Tube Spanner 7/8
•
Silicone grease
•
Reassembly Procedures
must be completed.
