Minelab F3Ci Service Manual page 41

_______________________________________________________________________________________________________________________
Cables held in
Cable Router
Figure 67: Underneath
Hinge Cover
Fit the hinge cover making sure the protrusion on the underside of the hinge cover
•
engages into the slot on the detector body near the hinge. Fit the two screws
(45mm) into the hinge cover and tighten.
•
c. The coil has now been fitted to the detector. Check the assembly and all moving parts.
Insert batteries and then carry out mechanical & functional testing as described in Section
Mechanical & Functional
•
•
•
•
•
•
•
Figure 68: Fitting Hinge Cover
Testing.
Spring Latch
Spring Eyelet
located on pin of
Latch Hinge
41
F3Ci Service Manual
Hinge
2 -
