Minelab F3Ci Service Manual page 29

_______________________________________________________________________________________________________________________
Make sure all connectors are firmly in place and all wires and cables are positioned
•
so that they will not cause obstruction or get damaged when the two halves of the
main body are fitted together.
Check the coil socket nut (18mm) is done up tightly.
•
Finish assembling the detector by closing the detector body, as described in Section
b.
Closing the Detector Body
Battery Connector
Figure 42: Connecting Battery Connector
Figure 43: and Coil Socket Nut
29
F3Ci Service Manual
3.2 –
