Handle

3.6
a. The handle assembly is a line replaceable unit and Figure 77 illustrates the major parts of
the handle.
0705-0082
31-03512-982
8005-0069
0705-0082
4006-0038
4308-0023
1 3004-0132
2 0703-0207
4 31-03512-982
5 4006-0038
6 4006-0041
7 4308-0022
8 4308-0023
9 4308-0024
10 4308-0026
11 4311-0076
12 4311-0079
13 8005-0067
14 8005-0068
15 8005-0069
4006-0041
4308-0022
Figure 77: Handle Parts
Handle Kit, contains all items in this table.
Display Assembly LED
Screw 3.5x12 skt head
Spring Latch Hinge
Spring Handle Detent
Pin Lock Handle Detent
Pin Handle Main Lower
Pin Handle Main Upper
Pin Spring Latch hinge
Hinge Handle Slide
Lock Handle Slide
Handle Main
Handle Forward Right
Handle Forward Left
Table 5: Handle Parts
46
4308-0026
8005-0068
4308-0024
8005-0067
4311-0076
4311-0079
