1 3004-0133
6 4311-0089
3.3.1 Removin t e Main PCB
a. To remove the main PCB, open the detector body as described in section
the Detector Body and:
Remove the Nut (18mm) from the coil connector. Figure 31.
•
Figure 29: Parts of the Main PCB
Main PCB Kit, contains all parts in this table.
Bracket Main PCB
Table 1: Parts of Main PCB
Figure 30: Opened Detector Body
23
F3Ci Service Manual
3.1 - Opening
