SEAT, FUEL TANK AND COVER _
_~_
3-4
4 . Remove :
• Cover (fuel tank)
CD
NOTE : ________________________ _
When removing the cover
CD,
remove the bolt
® .
Then pull the projections
@
from the grom-
mets.
5.
Turn the fuel cock to " OFF" .
6.
Disconnect:
• Fuel hose
CD
NOTE: ________________________ _
Place a rug on the engine to absorb a spilt fuel.
AWARNING
Gasoline is highly flammable.
Aboid spilling fuel on the hot engine.
7. Di sconnect :
-Flap
®
-Vacuum hose
@
- Roll over valve hose
@
(XT600EAC)
8 . Remove :
-Fuel tank
