OWNER'S MANUAL
XT660RW
XT660XW
5VK-F8199-21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XT660RW and is the answer not in the manual?

Questions and answers

Related Manuals for Yamaha XT660RW

Summary of Contents for Yamaha XT660RW

  • Page 1 OWNER’S MANUAL XT660RW XT660XW 5VK-F8199-21...
  • Page 3 EAU10100 Welcome to the Yamaha world of motorcycling! As the owner of the XT660R/XT660X, you are benefiting from Yamaha’s vast experience and newest technology regarding the design and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
  • Page 4 This manual should be considered a permanent part of this motorcycle and should remain with it even if the motorcycle is subsequently sold. Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most current product information available at the time of printing, there may be minor discrepancies between your motorcycle and this manual.
  • Page 5 IMPORTANT MANUAL INFORMATION EAUM1010 XT660RW/XT660XW OWNER’S MANUAL ©2006 by MBK INDUSTRIE 1st edition, July 2006 All rights reserved Any reprinting or unauthorized use without the written permission of MBK INDUSTRIE is expressly prohibited. Printed in France.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS SAFETY INFORMATION ....1-1 OPERATION AND IMPORTANT Adjusting the rear brake light Location of important labels ....1-5 RIDING POINTS......... 5-1 switch ........6-22 Starting and warming up a cold Checking the front and rear brake DESCRIPTION ........2-1 engine ......... 5-1 pads ..........
  • Page 7 TABLE OF CONTENTS Troubleshooting charts ....6-40 MOTORCYCLE CARE AND STORAGE ..........7-1 Care ..........7-1 Storage ...........7-3 SPECIFICATIONS ......8-1 CONSUMER INFORMATION.....9-1 Identification numbers ....9-1 Motorcycle noise regulation (for Australia) ......9-2...

  • Page 8: Safety Information

    SAFETY INFORMATION EAU10311 AND/OR WHEN MADE NECES- • Ride where other motorists can SARY BY MECHANICAL CONDI- see you. Avoid riding in another MOTORCYCLES SINGLE TIONS. motorist’s blind spot. TRACK VEHICLES. THEIR SAFE USE Many accidents involve inexperi- AND OPERATION ARE DEPENDENT Safe riding enced operators.
  • Page 9 Modifications made to this motorcycle gle for the speed). cycle accidents are the result of head not approved by Yamaha, or the re- • Always obey the speed limit and injuries. The use of a safety helmet is moval of original equipment, may ren-...
  • Page 10 SAFETY INFORMATION When loading within this weight limit, stallation and use of non-Yamaha namic effects. Wind may at- keep the following in mind: accessories. Use extreme caution tempt to lift the motorcycle, or Cargo accessory weight when selecting and installing any ac-...
  • Page 11 SAFETY INFORMATION • Take care not to spill any gaso- • Do not park the motorcycle near line on the engine or exhaust a flammable source (e.g., a ker- system when refueling. osene heater, or near an open • Never refuel while smoking or in flame), otherwise it could catch the vicinity of an open flame.

  • Page 12: Location Of Important Labels

    SAFETY INFORMATION EAU10381 Location of important labels Please read the following important labels carefully before operating this vehicle. 4CU-F1568-00...

  • Page 13: Description

    DESCRIPTION EAU10410 Left view 1. Windshield 9. Seat lock (page 3-12 ) 2. Idle adjusting screw (page 6-17) 10.Shift pedal (page 3-9) 3. Main fuse (page 6-32) 11.Engine oil drain bolt (crankcase) (page 6-10) 4. Battery (page 6-30) 5. Fuse box 1 (page 6-32) 6.

  • Page 14: Right View

    DESCRIPTION EAU10420 Right view 1. Owner’s tool kit (page 6-1) 9. Engine oil filter element (page 6-10) 2. Air filter element (page 6-16) 10.Coolant drain bolt (page 6-14) 3. Shock absorber assembly spring preload adjusting ring (page 3-13) 11.Brake pedal (page 3-9) 4.

  • Page 15: Controls And Instruments

    DESCRIPTION EAU32240 Controls and instruments XT660R 1. Clutch lever (page 3-8) 8. Fuel tank cap (page 3-10) 2. Left handlebar switches (page 3-7) 3. Main switch/steering lock (page 3-2) 4. Multi-function display (page 3-5) 5. Right handlebar switches (page 3-7) 6.
  • Page 16 DESCRIPTION XT660X 1. Clutch lever (page 3-8) 2. Left handlebar switches (page 3-7) 3. Main switch/steering lock (page 3-2) 4. Multi-function display (page 3-5) 5. Right handlebar switches (page 3-7) 6. Brake lever (page 3-9) 7. Throttle grip (page 6-18) 8.

  • Page 17: Instrument And Control Functions

    Do not expose any key to exces- a Yamaha dealer to have them re-reg- sively high temperatures. istered. Do not use the key with the red Do not place any key close to bow for driving.

  • Page 18: Main Switch/Steering Lock

    INSTRUMENT AND CONTROL FUNCTIONS EAU10471 EAU10570 To lock the steering Main switch/steering lock All electrical circuits are supplied with power; the meter lighting, taillight and auxiliary light come on, and the engine can be started. The key cannot be re- moved.

  • Page 19: Indicator And Warning Lights

    INSTRUMENT AND CONTROL FUNCTIONS To unlock the steering EAU33001 EAU11003 (Parking) Indicator and warning lights The steering is locked, and the taillight and auxiliary light are on. The hazard lights and turn signal lights can be turned on, but all other electrical sys- tems are off.
  • Page 20 If the indicator light does not come on for a few seconds, and then go off, Yamaha dealer check the electrical cir- for a few seconds, then go off, have a have a Yamaha dealer check the elec- cuit. Yamaha dealer check the electrical cir- trical circuit.

  • Page 21: Multi-Function Display

    INSTRUMENT AND CONTROL FUNCTIONS This model is also equipped with a self- EAUM1960 a fuel reserve tripmeter (which Multi-function display diagnosis device for the immobilizer shows the distance traveled since system. (See page 3-5 for an explana- the fuel level warning light came tion of the self-diagnosis device.) a clock a self-diagnosis device...
  • Page 22 NOTE: To set the clock: ber, and then have a Yamaha dealer Make sure there are no other immobi- 1. Push the “SELECT” button and check the vehicle. lizer keys close to the main switch, and “RESET”...

  • Page 23: Handlebar Switches

    Yamaha dealer and have the stan- dard keys re-registered. Left If the multi-function display indicates any error codes, note the code number, and then have a Yamaha dealer check the vehicle. 1. Engine stop switch “ ” 2. Start switch “...

  • Page 24: Clutch Lever

    INSTRUMENT AND CONTROL FUNCTIONS position. To cancel the turn signal EAU12733 EAU12820 Hazard switch “ ” Clutch lever lights, push the switch in after it has re- With the key in the “ON” or “ ” posi- turned to the center position. tion, use this switch to turn on the haz- ard lights (simultaneous flashing of all EAU12500...

  • Page 25: Shift Pedal

    INSTRUMENT AND CONTROL FUNCTIONS EAU12870 EAU12890 EAU12941 Shift pedal Brake lever Brake pedal 1. Shift pedal 1. Brake lever 1. Brake pedal The shift pedal is located on the left The brake lever is located at the right The brake pedal is on the right side of side of the engine and is used in com- handlebar grip.

  • Page 26: Fuel Tank Cap

    INSTRUMENT AND CONTROL FUNCTIONS EAUM1791 EAU13211 Fuel tank cap NOTE: Fuel The fuel tank cap cannot be installed unless the key is in the lock. In addition, the key cannot be removed if the cap is not properly installed and locked. EWA11140 WARNING Make sure that the fuel tank cap is...

  • Page 27: Catalytic Converter

    Do not allow the engine to idle as well as to the exhaust system. too long. Your Yamaha engine has been de- signed to use premium unleaded gaso- line with a research octane number of 95 or higher. If knocking (or pinging) oc-...

  • Page 28: Seat

    INSTRUMENT AND CONTROL FUNCTIONS EAU13900 EAU14451 Seat Storage compartment To remove the seat 1. Insert the key into the seat lock, and then turn it as shown. 1. Seat holder 2. Projection 1. Storage compartment 2. Push the rear of the seat down to The storage compartment is located lock it in place.

  • Page 29: Adjusting The Shock Absorber Assembly

    INSTRUMENT AND CONTROL FUNCTIONS When washing the vehicle, be careful EAU14830 crease the spring preload and thereby Adjusting the shock absorber not to let any water enter the storage soften the suspension, turn the adjust- assembly compartment. ing ring in direction (b). NOTE: Align the appropriate notch in the ad- justing ring with the position indicator...

  • Page 30: Sidestand

    INSTRUMENT AND CONTROL FUNCTIONS Do not subject the shock ab- EAU15301 below and have a Yamaha dealer re- Sidestand sorber to an open flame or other pair it if it does not function proper- The sidestand is located on the left side high heat sources, otherwise it of the frame.

  • Page 31: Ignition Circuit Cut-Off System

    Periodically check the operation of the ignition circuit cut-off system according to the following procedure. EWA10250 WARNING If a malfunction is noted, have a Yamaha dealer check the system be- fore riding. 3-15...
  • Page 32 5. Push the start switch. Does the engine start? The neutral switch may be defective. The motorcycle should not be ridden until checked by a Yamaha dealer. With the engine still running: 6. Move the sidestand up. 7. Keep the clutch lever pulled.

  • Page 33: Pre-Operation Checks

    PRE-OPERATION CHECKS EAU15591 The condition of a vehicle is the owner’s responsibility. Vital components can start to deteriorate quickly and unexpectedly, even if the vehicle remains unused (for example, as a result of exposure to the elements). Any damage, fluid leakage or loss of tire air pressure could have serious consequences.

  • Page 34: Pre-Operation Check List

    • If necessary, add recommended coolant to specified level. 6-13 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 35 • Make sure that operation is smooth. • Check cable free play. Throttle grip 6-18, 6-27 • If necessary, have Yamaha dealer adjust cable free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 6-27 •...

  • Page 36: Operation And Important Riding Points

    Always make sure described on page 3-15. Yamaha dealer check the electrical cir- that there is adequate ventila- Never ride with the sidestand cuit. tion. down.

  • Page 37: Shifting

    OPERATION AND IMPORTANT RIDING POINTS serve the battery. Do not crank the en- EAU16671 ECA10260 Shifting CAUTION: gine more than 10 seconds on any one attempt. Even with the transmission in the neutral position, do not ECA11130 coast for long periods of time CAUTION: with the engine off, and do not For maximum engine life, always...

  • Page 38: Tips For Reducing Fuel Consumption

    During this period, prolonged full-throt- ting it idle for an extended length of immediately have a Yamaha dealer tle operation or any condition that might time (e.g., in traffic jams, at traffic check the vehicle.

  • Page 39: Parking

    OPERATION AND IMPORTANT RIDING POINTS EAU17212 Parking When parking, stop the engine, and then remove the key from the main switch. EWA10310 WARNING Since the engine and exhaust system can become very hot, park in a place where pedestri- ans or children are not likely to touch them.

  • Page 40: Periodic Maintenance And Minor Repair

    Safety is an obligation of the owner. Pe- ence required for a particular job, have riodic inspection, adjustment and lubri- a Yamaha dealer perform it for you. cation will keep your vehicle in the safest and most efficient condition pos- EWA10350 sible.

  • Page 41: Periodic Maintenance And Lubrication Chart

    The annual checks must be performed every year, except if a kilometer-based maintenance is performed in- stead. From 50000 km, repeat the maintenance intervals starting from 10000 km. Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills. ODOMETER READING (× 1000 km)
  • Page 42 PERIODIC MAINTENANCE AND MINOR REPAIR ODOMETER READING (× 1000 km) ANNUAL ITEM CHECK OR MAINTENANCE JOB CHECK • Check runout, spoke tightness and for damage. √ √ √ √ √ 9 * Wheels • Tighten spokes if necessary. • Check tread depth and for damage. •...
  • Page 43 PERIODIC MAINTENANCE AND MINOR REPAIR ODOMETER READING (× 1000 km) ANNUAL ITEM CHECK OR MAINTENANCE JOB CHECK √ √ √ Engine oil filter element • Replace. √ √ √ √ √ • Check coolant level and vehicle for coolant leakage. 24 * Cooling system •...

  • Page 44: Removing And Installing Cowlings And Panels

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU18712 XT660X XT660X Removing and installing cowl- ings and panels The cowlings and panels shown need to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time a cowling or panel needs to be re- moved and installed.
  • Page 45 PERIODIC MAINTENANCE AND MINOR REPAIR XT660X XT660R 1. Protector 1. Cowling B 1. Bolt 2. Cowling bracket tab 2. Panel B 3. Bracket XT660X 2. Place the cowling in the original EAUM1682 Cowling A position, and then install the bolts and spacers.
  • Page 46 PERIODIC MAINTENANCE AND MINOR REPAIR EAUM2130 Cowling B (XT660X) To remove the cowling 1. Remove the seat and panel B. (See pages 3-12 and 6-5.) 2. Remove the bolts, and then re- move the quick fastener screw by turning it 1/4 turn counterclock- wise.
  • Page 47 PERIODIC MAINTENANCE AND MINOR REPAIR EAUM1710 Panel B To remove the panel 1. Remove the seat. (See page 3-12.) 2. Remove the bolt, and then pull the panel off at the areas shown. 1. Bolt 2. Install the seat. 2. Spacer To install the panel 1.

  • Page 48: Checking The Spark Plug

    Do not attempt to diagnose such problems yourself. In- 1. Spark plug gap stead, have a Yamaha dealer check 1. Spark plug cap the vehicle. Spark plug gap: 2. Remove the spark plug as shown, 0.7–0.8 mm (0.028–0.031 in)

  • Page 49: Engine Oil And Oil Filter Element

    PERIODIC MAINTENANCE AND MINOR REPAIR 2. Clean the surface of the spark plug EAUM1841 Engine oil and oil filter ele- NOTE: gasket and its mating surface, and The engine oil tank is located in- ment then wipe off any grime from the side of the frame.
  • Page 50 PERIODIC MAINTENANCE AND MINOR REPAIR EWA10360 WARNING Never remove the engine oil tank cap after high-speed operation, oth- erwise hot engine oil could spout out and cause damage or injury. Al- ways let the engine oil cool down sufficiently before removing the oil tank cap.
  • Page 51 PERIODIC MAINTENANCE AND MINOR REPAIR 9. Install the oil filter element cover by ECAM1060 CAUTION: installing the bolts and the oil filter element drain bolt, then tightening The engine oil tank must be filled in them to the specified torques. 2 steps.

  • Page 52: Coolant

    PERIODIC MAINTENANCE AND MINOR REPAIR addition, do not use oils labeled EAU20070 Coolant “ENERGY CONSERVING II” or The coolant level should be checked higher. before each ride. In addition, the cool- Make sure that no foreign mate- ant must be changed at the intervals rial enters the crankcase.
  • Page 53 If water has been added to the 2. Remove the seat and panel B. 7. Remove the coolant reservoir coolant, have a Yamaha dealer (See pages 3-12 and 6-5.) bolts, and then turn the coolant check the antifreeze content of 3.
  • Page 54 If water has been added to the diator and reservoir. coolant, have a Yamaha dealer check the antifreeze content of Antifreeze/water mixture ratio: the coolant as soon as possible, Recommended antifreeze:...

  • Page 55: Replacing The Air Filter Element And Cleaning The Check Hose

    Replace the air filter element the vehicle for coolant leakage. If more frequently if you are riding in un- coolant is leaking, have a Yamaha usually wet or dusty areas. In addition, dealer check the cooling system. the air filter check hose must be fre- 18.

  • Page 56: Adjusting The Engine Idling Speed

    PERIODIC MAINTENANCE AND MINOR REPAIR ECA10480 EAUM1910 Adjusting the engine idling CAUTION: speed Make sure that the air filter ele- The engine idling speed must be ment is properly seated in the checked and, if necessary, adjusted as air filter case. follows at the intervals specified in the The engine should never be op- periodic maintenance and lubrication...

  • Page 57: Checking The Throttle Cable Free Play

    Yamaha dealer make the adjustment. sary, have a Yamaha dealer adjust it. The tire air pressure must be ad- justed in accordance with the riding speed and with the total...
  • Page 58 Front: XT660R 200 kPa (29 psi) (2.00 Securely pack the heaviest sidewall is cracked, have a Yamaha kgf/cm²) items close to the center of the dealer replace the tire immediately. Rear: motorcycle and distribute the XT660R 200 kPa (29 psi) (2.00...
  • Page 59 When a tire tread with the local regulations. XT660X 120/70R17 M/C 58H, begins to show crosswise lines, 120/70ZR17 M/C 58W, have a Yamaha dealer replace 120/70ZR17 M/C 58W the tire immediately. Tire information Manufacturer/model: The replacement of all wheel-...

  • Page 60: Spoke Wheels

    (a) to loos- age before each ride. If any dam- en the clutch cable. age is found, have a Yamaha 4. Loosen the locknut at the crank- dealer replace the wheel. Do not case.

  • Page 61: Adjusting The Rear Brake Light Switch

    PERIODIC MAINTENANCE AND MINOR REPAIR 5. To increase the clutch lever free EAU22270 EAU22390 Adjusting the rear brake light Checking the front and rear play, turn the adjusting nut in direc- switch brake pads tion (a). To decrease the clutch le- The front and rear brake pads must be ver free play, turn the adjusting nut checked for wear at the intervals spec-...

  • Page 62: Checking The Brake Fluid Level

    EAU22580 Before riding, check that the brake fluid Checking the brake fluid level peared, have a Yamaha dealer replace is above the minimum level mark and the brake pads as a set. replenish if necessary. A low brake fluid...

  • Page 63: Drive Chain Slack

    NOTE: ually go down. However, if the brake fluid level goes down sud- When checking the drive chain slack, denly, have a Yamaha dealer the chain tensioner should not be check the cause. touching the drive chain. EAU22932 1.
  • Page 64 PERIODIC MAINTENANCE AND MINOR REPAIR 3. Tighten the locknuts, and then NOTE: tighten the axle nut to the specified Using the alignment marks on each torque. side of the swingarm, make sure that both adjusting nuts are in the same po- Tightening torque: sition for proper wheel alignment.

  • Page 65: Cleaning And Lubricating The Drive Chain

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU23022 ECA11110 Tightening torques: Cleaning and lubricating the CAUTION: Locknut: drive chain Do not use engine oil or any other lu- 16 Nm (1.6 m·kgf, 11 ft·lbf) The drive chain must be cleaned and Axle nut: bricants for the drive chain, as they 104 Nm (10.4 m·kgf, 75 ft·lbf) lubricated at the intervals specified in...

  • Page 66: Checking And Lubricating The Cables

    If a cable is damaged maintenance chart. or does not move smoothly, have a Yamaha dealer check or replace it. Recommended lubricant: Engine oil EWA10720 Clutch lever...

  • Page 67: Lubricating The Brake Pedal

    Recommended lubricant: necessary. Lithium-soap-based grease (all-pur- EWA10730 pose grease) WARNING If the sidestand does not move up and down smoothly, have a Yamaha dealer check or repair it. Recommended lubricant: Lithium-soap-based grease (all-pur- pose grease) 6-28...

  • Page 68: Checking The Front Fork

    Securely support the vehicle so that fork does not operate smoothly, damage and excessive oil leakage. there is no danger of it falling over. have a Yamaha dealer check or re- pair it. To check the operation 2. Hold the lower ends of the front 1.

  • Page 69: Checking The Wheel Bearings

    If there is play in the wheel need to check the electrolyte or to add hub or if the wheel does not turn distilled water. smoothly, have a Yamaha dealer check ECA10620 CAUTION: the wheel bearings. Never attempt to remove the battery cell seals, as this would permanent- ly damage the battery.
  • Page 70 To charge the battery vide sufficient ventilation when To charge a sealed-type (MF) Have a Yamaha dealer charge the bat- charging it in an enclosed battery, a special (constant-volt- tery as soon as possible if it seems to space.

  • Page 71: Replacing The Fuses

    PERIODIC MAINTENANCE AND MINOR REPAIR EAUM1740 Specified fuses: Replacing the fuses Main fuse: The main fuse is located behind panel 30.0 A A. (See page 6-5.) Fuse box 1: Headlight fuse: 20.0 A Signaling system fuse: 10.0 A Radiator fan fuse: 7.5 A Ignition fuse: 1.

  • Page 72: Replacing The Headlight Bulb

    PERIODIC MAINTENANCE AND MINOR REPAIR 4. If the fuse immediately blows EAUM1750 Replacing the headlight bulb again, have a Yamaha dealer This model is equipped with a quartz check the electrical system. bulb headlight. If the headlight bulb burns out, replace it as follows.

  • Page 73: Replacing A Turn Signal Light Bulb Or The Tail/Brake Light Bulb

    1. Do not touch the glass part of the bulb. 1. Screw 5. Install the bulb cover, and then connect the coupler. 6. Install the cowling together with the headlight unit. 7. Have a Yamaha dealer adjust the headlight beam if necessary. 1. Screw 6-34...

  • Page 74: Replacing An Auxiliary Light Bulb

    PERIODIC MAINTENANCE AND MINOR REPAIR EAUM1820 EAU24350 a jack either under each side of the Replacing an auxiliary light Supporting the motorcycle frame in front of the rear wheel or under bulb Since this model is not equipped with a each side of the swingarm.

  • Page 75: Front Wheel

    XT660X Front wheel EAUM1761 To remove the front wheel EWA10820 WARNING It is advisable to have a Yamaha dealer service the wheel. Securely support the motor- cycle so that there is no danger 1. Bolt 1. Wheel axle of it falling over.

  • Page 76: Rear Wheel

    Make sure that there is enough space EWA10820 between the brake pads before install- WARNING ing the brake caliper onto the brake It is advisable to have a Yamaha disc. dealer service the wheel. 5. Tighten the wheel axle to the spec- Securely support the motor- ified torque.
  • Page 77 PERIODIC MAINTENANCE AND MINOR REPAIR XT660X 1. Brake caliper 1. Axle nut NOTE: 2. Brake disc 2. Drive chain slack adjusting bolt The drive chain cannot be disassem- 3. Locknut bled. EAUM2140 To install the rear wheel 4. Brake caliper bracket 5.

  • Page 78: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.

  • Page 79: Troubleshooting Charts

    Remove the spark plug and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the battery. 4. Battery The engine turns over The battery is good.
  • Page 80 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. NOTE: If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.

  • Page 81: Motorcycle Care And Storage

    MOTORCYCLE CARE AND STORAGE EAU26001 ucts onto seals, gaskets, sprock- cleaning products, solvent or Care ets, the drive chain and wheel thinner, fuel (gasoline), rust re- While the open design of a motorcycle axles. Always rinse the dirt and de- movers or inhibitors, brake flu- reveals the attractiveness of the tech- greaser off with water.
  • Page 82 MOTORCYCLE CARE AND STORAGE After normal use ECA10790 5. Use spray oil as a universal clean- CAUTION: Remove dirt with warm water, a mild er to remove any remaining dirt. detergent, and a soft, clean sponge, 6. Touch up minor paint damage Do not use warm water since it in- and then rinse thoroughly with clean caused by stones, etc.

  • Page 83: Storage

    CAUTION: NOTE: the spark plug, and then place Storing the motorcycle in a Consult a Yamaha dealer for advice on the spark plug on the cylinder poorly ventilated room or cover- what products to use. head so that the electrodes are ing it with a tarp, while it is still grounded.
  • Page 84 MOTORCYCLE CARE AND STORAGE 4. Lubricate all control cables and the pivoting points of all levers and pedals as well as of the side- stand/centerstand. 5. Check and, if necessary, correct the tire air pressure, and then lift the motorcycle so that both of its wheels are off the ground.

  • Page 85: Specifications

    SPECIFICATIONS Dimensions: Compression ratio: Air filter: 10.00 :1 Overall length: Air filter element: Starting system: XT660R 2240 mm (88.2 in) Oil-coated paper element Electric starter XT660X 2175 mm (85.6 in) Fuel: Lubrication system: Overall width: Recommended fuel: Dry sump XT660R 845 mm (33.3 in) Premium unleaded gasoline only Engine oil: XT660X 860 mm (33.9 in)
  • Page 86 SPECIFICATIONS Operation: Manufacturer/model: Rear: Left foot operation XT660R METZELER/TOURANCE XT660R 200 kPa (29 psi) (2.00 kgf/cm²) Gear ratio: FRONT, XT660X 210 kPa (30 psi) (2.10 kgf/cm²) 1st: MICHELIN/SIRAC Loading condition: 30/12 (2.500) XT660X PIRELLI/DRAGON, 90–186 kg (198–410 lb) 2nd: METZELER/SPORTEC M1, Front: 26/16 (1.625) MICHELIN/RADIAL PILOT SPORT...
  • Page 87 SPECIFICATIONS Recommended fluid: Voltage, capacity: Fuses: DOT 4 12 V, 8.0 Ah Main fuse: Rear brake: Headlight: 30.0 A Type: Bulb type: Headlight fuse: Single disc brake Halogen bulb 20.0 A Bulb voltage, wattage × quantity: Operation: Signaling system fuse: Right foot operation 10.0 A Headlight:...

  • Page 88: Consumer Information

    Record the key identification number, vehicle identification number and mod- el label information in the spaces pro- vided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehi- cle is stolen. KEY IDENTIFICATION NUMBER: 1.

  • Page 89: Motorcycle Noise Regulation (For Australia)

    This information b. The use of the vehicle after such will be needed when ordering spare device or element of design has parts from a Yamaha dealer. been removed or rendered inoper- ative by any person.
  • Page 90 INDEX Front fork, checking ......6-29 Periodic maintenance and lubrication Fuel............3-10 chart............6-2 Air filter element and check hose, Fuel consumption, tips for reducing..5-3 Pre-operation check list......4-2 replacing and cleaning......6-16 Fuel level warning light ......3-4 Auxiliary light bulb, replacing ....6-35 Fuel tank cap ........
  • Page 91 INDEX Vehicle identification number....9-1 Wheel bearings, checking ....6-30 Wheel (front) ......... 6-36 Wheel (rear).......... 6-37 Wheels..........6-21...
  • Page 94 YAMAHA MOTOR CO., LTD. PRINTED IN FRANCE 2006.07 (E)
