Summary of Contents for Yamaha TENERE XT660Z

  • Page 1 OWNER’S MANUAL XT660Z 11D-F8199-E0...
  • Page 4 EAU26944 AMAHA MOTOR ELECTRONICS CO., LTD. 450-6, Mori, Mori-machi, Shuchi-gun, Shizuoka-ken, 437-0292 Japan DECLARATION of CONFORMITY Company: YAMAHA MOTOR ELECTRONICS CO., LTD. Address: 1450-6, Mori, Mori-Machi, Shuchi-gun, Shizuoka-Ken, 437-0292 Japan Hereby declare that the product: Kind of equipment: IMMOBILIZER Type-designation: 5SL-00 is in compliance with following norm(s) or documents: R&TTE Directive(1999/5/EC)
  • Page 5 Welcome to the Yamaha world of motorcycling! As the owner of the XT660Z Ténéré, you are benefiting from Yamaha’s vast experience and newest technology regarding the design and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.

  • Page 6: Important Manual Information

    Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most current product information available at the time of printing, there may be minor discrepancies between your mo- torcycle and this manual. If you have any questions concerning this manual, please consult your Yamaha dealer.. EWA10030 WARNING PLEASE READ THIS MANUAL CAREFULLY AND COMPLETELY BEFORE OPERATING THIS MOTORCYCLE.
  • Page 7 IMPORTANT MANUAL INFORMATION EAUB1011 XT660Z OWNER'S MANUAL ©2008 by Yamaha Motor Italia S.P.A. edition, march 2008 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Italia S.P.A. is expressly prohibited. Printed in the Italy.

  • Page 8: Table Of Contents

    TABLE OF CONTENTS Fuel tank cap ........3-11 Checking the spark plug ....6-8 SAFETY INFORMATION .....1-1 Engine oil and oil filter element..6-9 Fuel ..........3-12 Safe riding.........1-1 Fuel tank breather hose....3-13 Coolant..........6-12 Protective apparel ......1-2 Catalytic converter ......3-13 Replacing the air filter element Modifications ........1-2 and cleaning the check hose ..6-14 Seat..........3-14...
  • Page 9 TABLE OF CONTENTS Lubricating the rear suspension..6-27 SPECIFICATIONS .......8-1 Lubricating the swingarm pivots ..6-28 Checking the front fork....6-28 CONSUMER INFORMATION....9-1 Checking the steering .....6-29 Identification numbers.......9-1 Checking the wheel bearings..6-29 Battery..........6-30 Replacing the fuses ......6-31 Replacing a headlight bulb .....6-33 Tail/brake light .........6-34 Replacing a turn signal light bulb..6-34 Replacing the license plate...

  • Page 10: Safety Information

    SAFETY INFORMATION EAU10311 • Ride where other motorists can Safe riding see you. Avoid riding in another ● Always make pre-operation MOTORCYCLES SINGLE motorist's blind spot. checks. Careful checks may help TRACK VEHICLES. THEIR SAFE ● Many accidents involve inexperi- prevent an accident.

  • Page 11: Protective Apparel

    Modifications made to this motorcycle warranted by road and traffic cle accidents are the result of head in- not approved by Yamaha, or the re- conditions. juries. The use of a safety helmet is the moval of original equipment, may ren- •...
  • Page 12 If accessories Make sure to distribute the weight stallation and use of non-Yamaha ac- are added to the handlebar or as evenly as possible on both cessories. Use extreme caution when...

  • Page 13: Gasoline And Exhaust Gas

    SAFETY INFORMATION ● ● • Certain accessories can dis- Never start the engine or let it run When transporting the motorcycle place the operator from his or for any length of time in a closed in another vehicle, make sure that her normal riding position.

  • Page 14: Description

    DESCRIPTION EAU10410 Left view 1. Idle adjusting screw (page 6-15) 6. Shock absorber assembly/spring preload adjusting ring (page 3-16) 2. Owner’s tool kit (page 6-1) 7. Shift pedal (page 3-10) 3. Air filter element (page 6-14) 8. Engine oil drain bolt (crankcase) (page 6-10) 4.

  • Page 15: Right View

    DESCRIPTION EAU10420 Right view 10. Grab bar 15. Front brake fluid reservoir (page 6-22) 11. Main fuse (page 6-31) 16. Coolant drain bolt (page 6-12) 12. Battery (page 6-30) 17. Engine oil filter element (page 6-10) 13. Rear brake fluid reservoir (page 6-22) 18.

  • Page 16: Controls And Instruments

    DESCRIPTION EAU10430 Controls and instruments 1. Clutch lever (page 3-10) 6. Brake lever (page 3-11) 2. Left handlebar switches (page 3-9) 7. Engine oil filler cap/dipstick (page 6-9) 3. Multi-function meter unit and warning lights (page 3-3, 3-5) 8. Fuel tank cap (page 3-11) 4.

  • Page 17: Instrument And Control Functions

    ● Do not place any key close to Yamaha dealer to have them re-regis- magnets (this includes, but not tered. Do not use the key with the red limited to, products such as bow for driving.

  • Page 18: Main Switch/Steering Lock

    INSTRUMENT AND CONTROL FUNCTIONS EAU10471 EAU10550 To lock the steering Main switch/steering lock All electrical circuits are supplied with power, the meter lighting, taillight, li- cense plate light and auxiliary lights come on, and the engine can be start- ed. The key cannot be removed. NOTE: The headlights comes on automatical- ly when the engine is started and stay...

  • Page 19: Indicator And Warning Lights

    "ON". If the indicator light does not come on key to “OFF” or “LOCK”. for a few seconds, then go off, have a Yamaha dealer check the electrical cir- cuit.
  • Page 20 When this oc- If the indicator light does not come on self-diagnosis device for the immobi- curs, have a Yamaha dealer check the for a few seconds, then go off, have a lizer system. (See page 3-7 for an ex- self-diagnosis system.

  • Page 21: Multi-Function Display

    INSTRUMENT AND CONTROL FUNCTIONS EAUB1501 The multi-function display is equipped NOTE: Multi-function display with the following: ● Be sure to turn the key to "ON" ● a speedometer (which shows the before using the "SELECT" and "RESET" buttons. riding speed) ●...

  • Page 22: Tachometer

    INSTRUMENT AND CONTROL FUNCTIONS ton switches the display between the Tachometer Tripmeter and tachometer modes various tripmeter modes in the follow- ing order: F-TRIP TRIP 1 TRIP 2 F-TRIP To reset a tripmeter, select it by push- ing the "SELECT" button, and then push the "RESET"...

  • Page 23: Clock Mode

    4. Push the "RESET" button to set ing. is defective, all the segments will start the minutes. If this occurs, have a Yamaha dealer flashing. If this occurs, have a Yamaha 5. Push the "SELECT" button and dealer check the electrical circuit.

  • Page 24: Anti-Theft Alarm (Optional)

    This motorcycle can be equipped with times, and then quickly flashes two an optional anti-theft alarm by a Yama- times repeatedly, this error could be ha dealer. Contact a Yamaha dealer for caused by transponder interference. If more information. this occurs, try the following.

  • Page 25: Handlebar Switches

    INSTRUMENT AND CONTROL FUNCTIONS EAU12347 EAU12460 Right Turn signal switch “y” Handlebar switches To signal a right-hand turn, push this Left switch to “Δ”. To signal a left-hand turn, push this switch to “Ÿ”. When re- leased, the switch returns to the cen- ter position.

  • Page 26: Clutch Lever

    INSTRUMENT AND CONTROL FUNCTIONS EAU12733 EAU12820 EAU12870 Hazard switch “ ” Clutch lever Shift pedal With the key in the “ON” or F position, use this switch to turn on the hazard lights (simultaneous flashing of all turn signal lights). The hazard lights are used in case of an emergency or to warn other drivers when your vehicle is stopped where it...

  • Page 27: Brake Lever

    INSTRUMENT AND CONTROL FUNCTIONS EAU26822 EAU12941 EAU13072 Brake lever Brake pedal Fuel tank cap 1. Brake lever 1. Brake pedal 1. Lock cover 2. Position adjusting dial 2. Open 3. Arrow mark The brake pedal is on the right side of 4.

  • Page 28: Fuel

    INSTRUMENT AND CONTROL FUNCTIONS EAU13211 ECA10070 To close the fuel tank cap CAUTION: Fuel 1. Push the fuel tank cap into posi- Immediately wipe off spilled fuel tion with the key inserted in the with a clean, dry, soft cloth, since lock.

  • Page 29: Fuel Tank Breather Hose

    Make sure that the exhaust system has cooled down before doing any maintenance work. Your Yamaha engine has been de- signed to use premium unleaded gasoline with a research octane num- 1. Fuel tank breather hose 2. Clamp ber of 95 or higher.

  • Page 30: Seat

    INSTRUMENT AND CONTROL FUNCTIONS ECA10700 EAU13870 To install the seat CAUTION: Seat The following precautions must be To remove the seat observed to prevent a fire hazard or other damages. ● Use only unleaded gasoline. The use of leaded gasoline will cause unrepairable damage to the catalytic converter.

  • Page 31: Adjusting The Front Fork

    INSTRUMENT AND CONTROL FUNCTIONS EAUB1550 EWA10180 NOTE: WARNING Adjusting the front fork Use the 10 mm hexagon wrench in- Always adjust both fork legs equal- cluded in the owner’s tool kit to turn ly, otherwise poor handling and the adjusting bolts. loss of stability may result.

  • Page 32: Adjusting The Shock Absorber Assembly

    Spring preload setting: will result in poor damping per- ECA10100 Minimum (soft): formance. CAUTION: ● Always have a Yamaha dealer Never attempt to turn an adjusting Standard: service the shock absorber. mechanism beyond the maximum or minimum settings. Maximum (hard):...

  • Page 33: Sidestand

    ● It cuts the running engine when or lower it with your foot while holding a Yamaha dealer repair it if it does the transmission is in gear and the motorcycle upright. not function properly.
  • Page 34 5. Push the start switch. Does the engine start? The neutral switch may be defective. The motorcycle should not be ridden until checked by a Yamaha dealer. With the engine still running: 6. Move the sidestand up. 7. Keep the clutch lever pulled.

  • Page 35: Pre-Operation Checks

    PRE-OPERATION CHECKS EAU15593 The condition of a vehicle is the owner’s responsibility. Vital components can start to deteriorate quickly and unexpected- ly, even if the vehicle remains unused (for example, as a result of exposure to the elements). Any damage, fluid leakage or loss of tire air pressure could have serious consequences.

  • Page 36: Pre-Operation Check List

    • If necessary, add recommended coolant to specified level. 6-12 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 37 • Make sure that operation is smooth. • Check cable free play. Throttle grip 6-16, 6-26 • If necessary, have Yamaha dealer adjust cable free play and lubricate cable and grip housing. • Make sure that operation is smooth. 6-25 Control cables •...
  • Page 38 PRE-OPERATION CHECKS ITEM CHECKS PAGE Instruments, lights, • Check operation. 3-3, 3-9 signals and switches • Correct if necessary. Sidestand • Check operation of ignition circuit cut-off system. 3-17 switch • If system is defective, have Yamaha dealer check vehicle.

  • Page 39: Operation And Important Riding Points

    ● The transmission is in the neutral ● Neutral indicator light their functions before riding. position. Consult a Yamaha dealer re- ● Turn signal indicator light ● The transmission is in gear with garding any control or function ●...

  • Page 40: Shifting

    OPERATION AND IMPORTANT RIDING POINTS 3. Start the engine by pushing the EAU16671 ECA10260 CAUTION: Shifting start switch. ● Even with the transmission in NOTE: the neutral position, do not coast for long periods of time If the engine fails to start, release the with the engine off, and do not start switch, wait a few seconds, and tow the motorcycle for long...

  • Page 41: Tips For Reducing Fuel Consumption

    OPERATION AND IMPORTANT RIDING POINTS EAU16810 EAU16841 EAU17100 0-1000 km (0-600 mi) Tips for reducing fuel Engine break-in Avoid prolonged operation above consumption There is never a more important peri- 4500 r/min. od in the life of your engine than the Fuel consumption depends largely on period between 0 and 1600 km (1000 your riding style.

  • Page 42: Parking

    ● If any engine trouble should oc- switch. cur during the engine break-in EWA10310 period, immediately have a WARNING Yamaha dealer check ● Since the engine and exhaust vehicle. system can become very hot, park in a place where pedestri- ans or children are not likely to touch them.

  • Page 43: Periodic Maintenance And Minor Repair

    If you do not have the tools or experi- Periodic inspection, adjustment and ence required for a particular job, have lubrication will keep your vehicle in the a Yamaha dealer perform it for you. safest and most efficient condition possible. The most important points of EWA10350...

  • Page 44: Periodic Maintenance And Lubrication Chart

    ● From 50000 km, repeat the maintenance intervals starting from 10000 km. ● Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and tech- nical skills. ODOMETER READING (x 1,000 km)
  • Page 45 PERIODIC MAINTENANCE AND MINOR REPAIR ODOMETER READING (x 1,000 km) ANNUAL ITEM CHECK OR MAINTENANCE JOB CHECK • Check for cracks or damage. √ √ √ √ √ Brake hoses ✻ • Replace. Every 4 years • Check runout, spoke tightness and for damage. Wheels ✻...
  • Page 46 PERIODIC MAINTENANCE AND MINOR REPAIR ODOMETER READING (x 1,000 km) ANNUAL ITEM CHECK OR MAINTENANCE JOB CHECK Front fork • Check operation and for oil leakage. ✻ √ √ √ √ Shock absorber • Check operation and shock absorber for oil ✻...
  • Page 47 PERIODIC MAINTENANCE AND MINOR REPAIR ODOMETER READING (x 1,000 km) ANNUAL ITEM CHECK OR MAINTENANCE JOB CHECK • Check the air cut-off valve, reed valve, and hose for damage. √ √ √ √ √ Air induction system ✻ • damage Muffler and exhaust •...

  • Page 48: Removing And Installing The Cowling And Panels

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU18722 Panel C and D Removing and installing the cowling and panels The cowling and panels shown need to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time the cowling or a panel needs to be removed and installed.
  • Page 49 PERIODIC MAINTENANCE AND MINOR REPAIR Panel E and F Panel G 1. Panel 1. Panel mounting bolt 2. Pin 1. Panel mounting bolt 2. Quick fastener G. Panel E. Right panel To install the panel F. Left panel Place the panel in the original position, To remove the panel and then install the bolts.

  • Page 50: Checking The Spark Plug

    Do not attempt to di- agnose such problems yourself. 1. Spark plug gap Instead, have a Yamaha dealer check the vehicle. Spark plug gap: 0.7-0.8 mm (0.028-0.032 in) 2. Check the spark plug for elec- trode erosion and excessive car- 2.

  • Page 51: Engine Oil And Oil Filter Element

    PERIODIC MAINTENANCE AND MINOR REPAIR EAUB1560 Tightening torque: Engine oil and oil filter Spark plug: element 12.5 Nm (1.25 m·kgf, 9.0 ft·lbf) The engine oil level should be checked before each ride. In addition, the oil must NOTE: be changed and the oil filter element re- If a torque wrench is not available placed at the intervals specified in the when installing a spark plug, a good...

  • Page 52: To Change The Engine Oil

    PERIODIC MAINTENANCE AND MINOR REPAIR ECA10010 To change the engine oil CAUTION: (with or without oil filter element Do not operate the vehicle until you replacement) know that the engine oil level is suf- ficient. EWA10360 WARNING Never remove the engine oil tank cap after high-speed operation, otherwise hot engine oil could 1.
  • Page 53 PERIODIC MAINTENANCE AND MINOR REPAIR 10. Install the oil filter element drain NOTE: Tightening torques: bolt. Skip steps 7-9 if the oil filter element is Oil filter element cover bolt: 11. Tighten the oil filter element cover 10 Nm (1.0 m·kgf, 7.2 ft·lbf) not being replaced.

  • Page 54: Coolant

    PERIODIC MAINTENANCE AND MINOR REPAIR ECAM1060 ECA11620 EAU20070 CAUTION: CAUTION: Coolant ● In order to prevent clutch slip- The engine oil tank must be filled in The coolant level should be checked 2 steps. First, fill the engine oil tank page (since the engine oil also before each ride.
  • Page 55 Have a Yamaha dealer change the coolant. Coolant reservoir capacity: 0.50 L (0.52 US qt) (0.44 Imp.qt) 6-13...

  • Page 56: Replacing The Air Filter Element And Cleaning The Check Hose

    PERIODIC MAINTENANCE AND MINOR REPAIR EAUB1480 To replace the air filter element Replacing the air filter element and cleaning the check hose The air filter element should be re- placed at the intervals specified in the periodic maintenance and lubrication chart.

  • Page 57: Checking The Engine Idling Speed

    2. If dirt or water is visible, remove checked as follows and, if necessary, the hose, clean it, and then install adjusted by a Yamaha dealer at the in- tervals specified in the periodic main- tenance and lubrication chart. Start the engine and warm it up for...

  • Page 58: Checking The Throttle Cable Free Play

    To prevent cycle, note the following points regard- this from occurring, the valve clear- ing the specified tires. ance must be adjusted by a Yamaha Tire air pressure dealer at the intervals specified in the The tire air pressure should be...
  • Page 59 PERIODIC MAINTENANCE AND MINOR REPAIR EWA11020 ● Adjust the suspension and tire WARNING air pressure with regard to the Tire air pressure Because loading has an enormous (measured on cold tires): load. impact on the handling, braking, Up to 90 kg (198 lb): ●...
  • Page 60 The tires must be checked before approved for this model by each ride. If the center tread depth Yamaha Motor Co., Ltd. reaches the specified limit, if the tire has a nail or glass fragments in it, or if the sidewall is cracked, have a Yama- ha dealer replace the tire immediately.

  • Page 61: Spoke Wheels

    130/80-17M/C 65S cluding the tires, should be left each ride. If any damage is found, 130/80-17M/C 65T Manufacturer/model: to a Yamaha dealer, who has have a Yamaha dealer replace the METZELER/TOURANCE necessary professional wheel. Do not attempt even the MICHELIN/SIRAC A knowledge and experience.

  • Page 62: Adjusting The Clutch Lever Free Play

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU22041 NOTE: Adjusting the clutch lever If the specified clutch lever free play free play could be obtained as described above, tighten the locknut and skip the rest of the procedure, otherwise proceed as follows. 3.

  • Page 63: Checking The Front And Rear Brake Pads

    1.0 mm To check the brake pad wear, check (0.04 in), have a Yamaha dealer re- the wear indicator groove. If a brake place the brake pads as a set.

  • Page 64: Checking The Brake Fluid Level

    Rear brake ● Use only the recommended qual- suddenly, have a Yamaha dealer ity brake fluid, otherwise the rub- check the cause. ber seals may deteriorate, caus- ing leakage and poor braking performance.

  • Page 65: Changing The Brake Fluid

    Changing the brake fluid Drive chain slack neutral position. 3. Move the rear wheel by pushing Have a Yamaha dealer change the The drive chain slack should be the motorcycle to locate the tight- brake fluid at the intervals specified in...
  • Page 66 PERIODIC MAINTENANCE AND MINOR REPAIR EAU34311 3. Tighten the locknuts, then the To adjust the drive chain slack axle nut to their specified torques. 1. Loosen the axle nut and the lock- nut on each side of the swingarm. 2. To tighten the drive chain, turn the Tightening torques: adjusting bolt on each side of the Locknut:...

  • Page 67: Cleaning And Lubricating The Drive Chain

    Service the drive aged or does not move smoothly, have they may contain substances that chain as follows. a Yamaha dealer check or replace it. could damage the O-rings. ECA10581 CAUTION: Recommended lubricant:...

  • Page 68: Checking And Lubricating The Throttle Grip And Cable

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU23111 EAU23141 The operation of the brake and clutch Checking and lubricating Checking and lubricating levers should be checked before each the throttle grip and cable the brake and clutch levers ride, and the lever pivots should be lu- bricated if necessary.

  • Page 69: Lubricating The Brake Pedal

    EWA10730 Recommended lubricant: WARNING Lithium-soap-based grease Recommended lubricant: If the sidestand does not move up Silicone grease and down smoothly, have a Yamaha dealer check or repair it. Recommended lubricant: Lithium-soap-based grease (all-purpose grease) 6-27...

  • Page 70: Lubricating The Swingarm Pivots

    If any damage is found or the front over. fork does not operate smoothly, have a Yamaha dealer check or re- Check the inner tubes for scratches, pair it. damage and excessive oil leakage.

  • Page 71: Checking The Steering

    If any free Worn or loose steering bearings may The front and rear wheel bearings play can be felt, have a Yamaha cause danger. Therefore, the opera- must be checked at the intervals spec- dealer check or repair the steering.

  • Page 72: Battery

    To charge the battery • INTERNAL: Drink large quan- Have a Yamaha dealer charge the bat- To access the battery tities of water or milk and im- tery as soon as possible if it seems to Remove the battery holder bracket by mediately call a physician.

  • Page 73: Replacing The Fuses

    If you do not have 4. After installation, make sure that access to a sealed-type (MF) the battery leads are properly battery charger, have a Yamaha 1. Main fuse connected to the battery termi- 2. Reserve fuse dealer charge your battery.
  • Page 74 2. Signaling system fuse Fuel injection system fuse: 4. If the fuse immediately blows 3. Headlight fuse 10 A again, have a Yamaha dealer 4. Ignition fuse Radiator fan fuse: 5. Electronic fuel injection fuse check the electrical system. 6. Radiator fan fuse 7.5 A...

  • Page 75: Replacing A Headlight Bulb

    PERIODIC MAINTENANCE AND MINOR REPAIR EAUB1580 EWA10790 WARNING Replacing a headlight bulb Headlight bulbs get very hot. There- fore, keep flammable products away from a lit headlight bulb, and do not touch the bulb until it has cooled down. 3. Place a new headlight bulb into position, and then secure it with 1.

  • Page 76: Tail/Brake Light

    4. Connect the coupler, and then in- 4. Install the lens by installing the stall the headlight bulb cover. screw. 5. Have a Yamaha dealer adjust the headlight beam if necessary. 6-34...

  • Page 77: Replacing The License Plate Light Bulb

    PERIODIC MAINTENANCE AND MINOR REPAIR ECA11190 EAUM2200 EAU42651 CAUTION: Replacing the license plate Replacing an auxiliary light light bulb bulb Do not overtighten the screw, oth- erwise the lens may break. 1. Bulb socket 1. Auxiliary light socket 2. License plate light bulb 2.

  • Page 78: Supporting The Motorcycle

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU24350 EAU24360 To service the rear wheel Supporting the motorcycle Front wheel Raise the rear wheel off the ground by EAUB1440 Since this model is not equipped with To remove the front wheel using a motorcycle stand or, if a mo- a centerstand, follow these precau- torcycle stand is not available, by plac- EWA10820...
  • Page 79 PERIODIC MAINTENANCE AND MINOR REPAIR 1. Loosen the front wheel axle pinch EAUB1470 6. Tighten wheel axle pinch bolt A, To install the front wheel bolts, the wheel axle and the and then pinch bolt B to the spec- 1. Lift the wheel up between the fork brake caliper bolts.

  • Page 80: Rear Wheel

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU25080 NOTE: Rear wheel ● If the drive chain is difficult to re- EAU25311 move, remove the wheel axle first, To remove the rear wheel EWA10820 and then lift the wheel upward WARNING enough to remove the drive chain from the rear sprocket.

  • Page 81: Troubleshooting

    However, should your motorcycle before installing the wheel. require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and 2. Install the drive chain onto the know-how to service the motorcycle rear sprocket.

  • Page 82: Troubleshooting Charts

    Remove the spark plug spark plug. and check the electrodes. The engine does not start. Have a Yamaha dealer check the Dry. Check the battery. vehicle. 4. Battery The engine turns The battery is good.
  • Page 83 Start the engine. If the engine overheats again, have is OK. a Yamaha dealer check and repair the cooling system. NOTE: If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.

  • Page 84: Motorcycle Care And Storage

    MOTORCYCLE CARE AND STORAGE ● EAU26000 3. Remove extremely stubborn dirt, Do not use any harsh chemical Care like oil burnt onto the crankcase, products on plastic parts. Be with a degreasing agent and a sure to avoid using cloths or While the open design of a motorcycle brush, but never apply such prod- sponges which have been in...
  • Page 85 MOTORCYCLE CARE AND STORAGE ● For motorcycles equipped with After riding in the rain, near the sea After cleaning a windshield: Do not use strong or on salt-sprayed roads 1. Dry motorcycle with cleaners or hard sponges as Since sea salt or salt sprayed on roads chamois or an absorbing cloth.

  • Page 86: Storage

    MOTORCYCLE CARE AND STORAGE EWA10930 NOTE: EAUM1900 WARNING Storage Consult a Yamaha dealer for advice on ● Make sure that there is no oil or Short-term what products to use. wax on the brakes or tires. If Always store your motorcycle in a cool,...
  • Page 87 MOTORCYCLE CARE AND STORAGE Long-term EWA10950 7. Remove the battery and fully WARNING Before storing your motorcycle for sev- charge it. Store it in a cool, dry To prevent damage or injury from eral months: place and charge it once a month. sparking, make sure to ground the 1.

  • Page 88: Specifications

    SPECIFICATIONS Dimensions: Engine oil: Air filter: Overall length: Type: Air filter element: 2246 mm (88.42 in) SAE10W30 or SAE10W40 or SAE15W40 Paper Overall width: or SAE20W40 or SAE20W50 Fuel: -20 -10 0 10 20 30 40 50 °C 864 mm (34.01 in) Recommended fuel: Overall height: Premium unleaded gasoline only...
  • Page 89 SPECIFICATIONS Operation: Manufacturer/model: Front wheel: Left foot operation METZELER/TOURANCE Type: Gear ratio: MICHELIN/SIRAC A Spoke wheel Rim size: Load: 30/12 (2.500) 21 x 1.85 Maximum load: 26/16 (1.625) Rear wheel: 190 kg (419 lb) Type: (Total weight of rider, passenger, cargo 23/20 (1.150) and accessories) Spoke wheel...
  • Page 90 SPECIFICATIONS Rear suspension: Neutral indicator light: Type: Turn signal indicator light: Swingarm (link suspension) Spring/damper type: High beam indicator light: Coil spring/gas-oil damper, spring preload adjustable Coolant temperature warning light: Wheel travel: 200 mm (7.87 in) Engine trouble warning light: Electrical system: Ignition system: Immobilizer system indicator light:...

  • Page 91: Consumer Information

    Record the key identification number, vehicle identification number and model label information in the spaces provided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the ve- hicle is stolen. KEY IDENTIFICATION NUMBER: 1.
  • Page 92 1. Model label The model label is affixed to the frame under the seat. (See page 3-14.) Record the information on this label in the space provided. This information will be needed when ordering spare parts from a Yamaha dealer.
  • Page 93 INDEX Checking and lubricating the Engine stop switch ......3-9 Air filter element, cleaning the sidestand ........6-27 Engine trouble warning light....3-4 check hose........6-14 Checking and lubricating the Air filter element, replacing ....6-14 throttle grip and cable ....6-26 Front fork ..........3-15 Anti-theft alarm (optional)....3-8 Checking the sidestand switch..3-18 Adjusting ........3-15 Auxiliary light bulb, replacing....6-35...
  • Page 94 INDEX Ignition circuit cut-off system....3-17 Model label.........9-2 Checking operation procedure..3-18 Multi-function display......3-5 Safety information ......1-1 Immobilizer system ......3-1 Clock mode........3-7 Seat..........3-14 Immobilizer system indicator light ..3-4 Self-diagnosis devices .......3-7 Self-diagnosis devices ....3-7 Indicator and warning lights ....3-3 Shift pedal ........3-10 Tachometer ........3-6 Coolant temperature warning Shifting ..........5-2...
  • Page 95 INDEX Tire information......6-18 Tire inspection ......6-18 Tool kit ..........6-1 Tripmeter and tachometer modes ..3-6 Troubleshooting ........6-39 Troubleshooting charts ....6-40 Engine overheating.......6-41 Turn signal indicator light ....3-3 Turn signal light bulb, replacing..6-34 Turn signal switch.......3-9 Valve clearance ........6-16 Vehicle identification number .....9-1 Warning lights ........3-3 Wheel bearings, checking ....6-29 Wheels, spoke........6-19...
  • Page 97 YAMAHA MOTOR ITALIA S.P.A. PRINTED IN ITALY...
