ENGINE REMOVAL
ENG
1'-1
4-3
STARTER MOTOR
1.
Remove:
• Oil delivery pipe
CD
2 .
Remove :
• Bolt
CD
(oil hose clamp)
3.
Disconnect :
• Starter motor lead
CD
• Ground lead
®
4. Remove:
.Starter motor
®
HOSE AN D LEAD
1.
Remove :
• Breather hose
CD
(oil tank)
• Breather hose
®
(crankcase)
2. Remove:
• Oil hose
CD
(inlet)
.Oil hose
®
(outlet)
