4. Alignment and Troubleshooting
► Error Code
M2–1110
M2–2210
► Error message
Paper Jam inside machine
Paper Jam inside of duplex
► Symptom
The jammed paper has occurred inside machine.
► Troubleshooting method
1) Open the rear cover. Remove the jammed paper.
2) If the problem persists, check the following.
a) Check if there is any obstacles or paper on the paper path. Remove it.
b) Check if the FRAME-REGI unit and FRAME-RATARD unit are assembled properly. If there is any defective
part in these units, replace it or Assy.
c) Check the motor operation, gear in the PH drive unit. If there is any defective parts, replace it or PH drive unit.
d) Check the T1–DRIVE unit. If there is any defective parts, replace it or T1–DRIVE unit.
